Savoy Piping Inc. is the worldwide biggest stockist supplier of the wide variety of the Hastelloy C22 Sheets. However, we are good at supplying the superior quality of the sheets and plates to the clients. On the other hand, the sheets and plates are also exported to the clients available all around the globe. The sheets and plates are provided in the cut made specifications of the clients as per their expectations. Some of the specifications in which the sheets and plates are available are surface finish, ends finish, dimensions, shapes, sizes, and length. Other than this, the sheets and plates are manufactured by following both national and international quality standards.
Our high-grade Hastelloy C22 Sheet/Plate is highly acceptable austenitic chromium, molybdenum, tungsten, and nickel alloy with well-enhanced pitting, crevice corrosion and stress corrosion cracking resistance. The high amount of chromium content is providing excellent resistance to oxidizing media. The nickel alloy gives good resistance ability to the oxidizing media that is including the wet chlorine and mixtures having oxidizing acid and nitric acid with the chloride ions.
Hastelloy C22 Sheets/Plates are applicable in many industries like offshore oil drilling industries, petrochemicals, power generation, chemical equipment, gad processing industry, food processing industry, specialty chemicals industry, pharmaceutical industry, pharmaceutical equipment, condensers, heat exchangers, paper industry, pulp industry and so on as well. These plates and sheets are applicable in many general purposes like aerospace industry, valves, shaft, Metal pickling amenities, electronics manufacturing, fuel reprocessing, nuclear plants, desulfurization scrubbers, and so on as well.
HASTELLOY® C-22® alloy (UNS N06022) is one of the well-known and well-proven nickel-chromium-molybdenum materials, the chief attributes of which are resistance to both oxidizing and non-oxidizing chemicals, and protection from pitting, crevice attack, and stress corrosion cracking. Its high chromium content provides much higher resistance to oxidizing media than the family standard, C-276 alloy, and imparts exceptional resistance to chloride-induced pitting, an insidious and unpredictable form of attack, to which the stainless steels are prone.
Like other nickel alloys, HASTELLOY® C-22® alloy is very ductile, exhibits excellent weldability, and is easily fabricated into industrial components. It is available in the form of plates, sheets, strips, billets, bars, wires, pipes, tubes, and covered electrodes. Typical chemical process industry (CPI) applications include reactors, heat exchangers, and columns.
Specifications | ASTM B575 / ASME SB575 |
---|---|
Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
Thickness | 0.1mm to 12 mm Thk |
Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Finish | Hot rolled plate (HR), Cold rolled sheet (CR). |
Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
STANDARD | WERKSTOFF NR. | UNS | JIS | EN | DIN | ISO |
Hastelloy C22 | 2.4602 | N06022 | NW 6022 | NiCr21Mo14W | 17750 | 6208 |
Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
Hastelloy C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
Sizes in Inches | Sizes in mm |
---|---|
.125" | 3.18mm |
.134" | 3.40mm |
.156" | 3.96mm |
.187" | 4.75mm |
.250" | 6.35mm |
.312" | 7.92mm |
.375" | 9.53mm |
.500" | 12.7mm |
.625" | 15.9mm |
.750" | 19.1mm |
.875" | 22.2mm |
1" | 25.4mm |
1.125" | 28.6mm |
1.250" | 31.8mm |
1.500" | 38.1mm |
1.750" | 44.5mm |
2" | 50.8mm |
2.500" | 63.5mm |
3" | 76.2mm |
UNS N06022 Plates | Hastelloy C-22 Slit Coils |
Hastelloy Alloy C22 Plates | Hastelloy C22 No 4 Finish Sheets |
C22 Hastelloy Sheets Manufacturer | C22 Hastelloy BA Finish Sheets |
ASME SB 575 TP C22 Hastelloy Sheets | Hastelloy C22 Bright Annealed Finish Plate |
Hastelloy C22 Coils Exporter | Hastelloy C22 Clad Plate |
C22 Hastelloy Cut to Size Plate | C22 Hastelloy Coils |
Alloy C22 Sheet & Plate | AISI C22 Sheets, Plates |
Hastelloy C22 Large Diameter Circle | Hastelloy C22 Coil Supplier |
Hastelloy C-22 Matte Sheet | Mirror Finish Hastelloy C22 Plates |
Jindal Hastelloy C22 Plates | Hastelloy Mill Finish #2 Sheet at Best Price |
Hastelloy C22 2B Finish Plates | ASTM B575 TPC22 Hastelloy Coils |
Hastelloy C22 Sheets | C22 Hastelloy Plates Stockist |
Hastelloy C22 Plasma Cutting Plate | Nickel Alloy C22 Rings |
Hastelloy C22 Sheets & Plates Supplier in Mumbai | Hastelloy C22 Blank Sheets |
Buy Now Hastelloy C22 Sheets at an Attactive Discounted Price, Order Above USD $ 25000 are Eligible of 2% Discount. We Offer Free Insurance and Best Shipping Rates. Our Prices are Always More Competitive and without any compromise in Quality of the Material.
Hastelloy C22 Sheets Available Thickness, Width and Length
Hastelloy C22 Sheets is Covered with Plastic Cloth and Packed in Wooden box-a, Wooden Pallet and Wooden Fumigated Carrate. Our Packaging is Fully Waterproof and Safe for Transport with Proper Strips on Wooden box-a, having Lifting Point.
