Grade 316 Stainless Steel is the standard molybdenum-bearing grade, second in importance to 304 amongst the austenitic stainless steels. The molybdenum gives 316 better overall corrosion resistant properties than Grade 304, particularly higher resistance to pitting and crevice corrosion in chloride environments. It has excellent forming and welding characteristics. It is readily brake or roll formed into a variety of parts for applications in the industrial, architectural, and transportation fields. Grade 316 also has outstanding welding characteristics. Post-weld annealing is not required when welding thin sections.
Grade 316L, the low carbon version of 316 and is immune from sensitisation (grain boundary carbide precipitation). Thus it is extensively used in heavy gauge welded components (over about 6mm). Grade 316H, with its higher carbon content has application at elevated temperatures, as does stabilised grade 316Ti.
The austenitic structure also gives these grades excellent toughness, even down to cryogenic temperatures
It is the preferred steel for use in marine environments because of its greater resistance to pitting corrosion than other grades of steel. The fact that it is negligibly responsive to magnetic fields means that it can be used in applications where a non-magnetic metal is required. In addition to molybdenum, 316 also contains a number of other elements in varying concentrations. Like other grades of stainless steel, marine grade stainless steel is a relatively poor conductor of both heat and of electricity when compared to metals and other conductive materials.
While 316 is not completely rust-proof, the alloy is more corrosion-resistant than other common stainless steels. Surgical steel is made from subtypes of 316 stainless steel.
Savoy Piping Inc., are recognized as the prominent Manufacturer, Trader and Supplier of a broad assortment of 316L Stainless Steel Plates. The offered steel plate is designed with utmost precision in conformity with the international quality standards.
An ISO 9001:2008 Certified Company, Savoy piping Inc., is a leading Stockholder, Supplier and Exporter of ASTM A240 316L Stainless Steel Plate. 316L Stainless Steel Plates are cut to your specifications and supplied with complete set of mill test reports. Custom length and width up to 2000 mm can be made available. Exports is Our Specialty! and we can source many hard to find grades and or non-standards sizes to meet the special requirements of our customers. All ASTM SS 316L Steel Plate can be cut to size with the help of our extensive expertise in processing steel Plate products.
Our stock of ASTM A240 316L Stainless Steel Plate includes thickness of 6mm up to 80mm with width of 1250mm, 1500mm, 2000mm.
|316L Stainless Steel Plate Specification||ASTM A240 / ASME SA240|
|316L Stainless Steel Manufacturing Process||Hot Rolled (HR) / Cold Rolled (CR)|
|316L Stainless Steel Plate Grades||202 / 304 / 304L / 304H / 309S / 310S / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc.
UNS No. - UNS S30400, UNS S30403, UNS S31008, UNS S31620, UNS S31603, UNS S31603, UNS S31635, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904
EN No. - 1.4301, 1.4307, 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539
|316L Stainless Steel Plate Thickness||0.6 MM TO 80 MM THICKNESS|
|316L Stainless Steel Plate Width||1250 MM / 1500 MM / 2000 MM / 04 Feet / 05 Feet and Custom Cut Width as Per Requirement|
|316L Stainless Steel Plate Length||2400 MM / 2420 MM / 6000 MM / 08 Feet / 10 Feet / Coil Cut and Custom Cut Length as Per Requirement|
|316L Stainless Steel Plate Surface Finish||2B, 2D, BA, MATT, MATT PVC, No.4, No.5, SB, HR, No.8, Mirror, Hairline, Brush, Textured, Oil base wet Polished, Both sides Polished available.|
|316L Stainless Steel Plate Coating||PVC coating Normal / Laser, Film: 100 micrometer, Color: black/white.|
|316L Stainless Steel Plate Other Testing||NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, etc.|
|316L Stainless Steel Plate Value Added Services||Gas Cutting / CNC Plasma Cutting / Profiling / Rolling / Bending / Sheet Metal Fabrication / Drill / Punch / Machining / Sand Blasting / Shot Blasting / Heat Treatment|
|316L Stainless Steel Plate Packaging||Loose / Carrate / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps|
|316L Stainless Steel Plate Shipment & Transportation||By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes|
|316L Stainless Steel Plate Material Test Certificate||Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC|
The chemical composition of grade 316L Stainless Steel is outlined in the following table
The mechanical properties of grade 316L Stainless Steel Plates are displayed in the following table.
(% in 50mm) min
|Rockwell B (HR B) max||Brinell (HB) max|
Physical properties of 316 grade stainless steel in the annealed condition
|Mean Co-eff of Thermal Expansion (µm/m/°C)||Thermal Conductivity
|Specific Heat 0-100°C
|0-100°C||0-315°C||0-538°C||At 100°C||At 500°C|
Possible alternative grades to 316L grade stainless steel
Steel no. k.h.s DIN
|1.4408||G-X 6 CrNiMo 18-10||316||S31600|
|1.4845||X 5 CrNi 2520||310S||S31008|
