Forged Fittings

Savoy Piping Inc. is a manufacturer and global supplier of forged fittings to ASME B16.11 and BS 3799 — socket weld and threaded elbows, tees, couplings, unions, caps, crosses, plugs, bushings, bosses, reducer inserts, swage nipples and bull plugs for small-bore process and utility piping.

We supply forged fittings in stainless steel (ASTM A182), carbon steel (A105, A350 LF2, A694), chrome-moly alloy (A182 F5–F91), duplex / super duplex, and nickel alloys including Inconel, Incoloy, Monel, Hastelloy, copper-nickel and titanium — matched to your pipe grade and pressure class.

Typical coverage spans ASME Classes 2000, 3000, 6000 and 9000, with mill test certificates (EN 10204 3.1 / 3.2), heat-number traceability and optional PMI, NACE and third-party inspection. Use the product grids below for forms and materials; use the PRODUCTS sidebar for category hubs.

Request Quote

Forged Fittings
Distributor of Top Quality Forged Fittings — Socket Weld & Threaded ASME B16.11 Providing high quality stainless, carbon, alloy, duplex and nickel forged fittings to customers in India and worldwide. Savoy Piping Inc. is a trusted manufacturer, stockholder and exporter of Class 3000 / 6000 / 9000 fittings with full MTC support. · Request quote

What are forged fittings?

Forged fittings are small-bore pipe fittings produced from forged steel or alloy stock, then machined to socket weld (SW) or threaded (screwed) ends. They join pipe, valves and instrumentation on lines where buttweld fittings are oversized or welding access is limited. Most industrial packages follow ASME B16.11 for dimensions and pressure–temperature ratings, with ASTM/ASME material specs for chemistry and mechanicals.

This page is the forged fittings category homepage for Savoy Piping Inc. Browse fitting forms and pressure classes in the grids below, and use the PRODUCTS sidebar for stainless, carbon, alloy, duplex, nickel and related hubs.

Standards that define the package

Dimensional control is usually ASME B16.11 (forged fittings, socket-welding and threaded) or BS 3799. Material is ordered to the ASTM forging specification that matches the pipe:

  • Stainless — ASTM A182 / ASME SA182 (F304, F304L, F316, F316L, F321, F347, F904L, F44 / SMO 254)
  • Carbon / LTCS / high-yield — ASTM A105, A350 LF2, A694
  • Chrome-moly alloy — ASTM A182 F5, F9, F11, F22, F91
  • Duplex / super duplex — UNS S31803 / S32205, S32750, S32760 (often A182 F51 / F53 / F55)
  • Nickel alloys — Inconel, Incoloy, Monel, Hastelloy, Alloy 20
  • Copper-nickel / titanium / brass — CuNi 90/10 & 70/30, Titanium Gr 2 / Gr 5, brass

Related hubs: Socket weld fittings · Threaded fittings · Swage nipples · Bull plugs.

Fitting forms we supply

Common ASME B16.11 forms stocked and made to order:

Sizes and pressure classes

Typical supply covers NPS 1/8" to 4" (project-dependent) in ASME Classes 2000, 3000, 6000 and 9000. Class must align with pipe schedule and design pressure. Socket weld and NPT/BSPT threaded ends are both available. Marking normally includes size, class, material grade, heat number and manufacturer identification for full traceability.

How to choose the right grade

What to put on the PO

Include material grade / ASTM class, end type (socket weld or threaded), fitting form, size, pressure class, quantity, destination, and documentation (EN 10204 3.1 / 3.2, PMI, NACE, TPI). Email sales@savoypipinginc.com.

Fitting forms

Socket weld & threaded ASME B16.11 shapes

Pressure classes & end types

Class 3000 / 6000 / 9000 · socket weld · threaded

Materials

Stainless · carbon · alloy · duplex · nickel alloys

Typical applications

  • Oil & gas process and utility small-bore piping
  • Refinery and petrochemical instrument / drain / vent lines
  • Power plant auxiliary and high-temperature chrome-moly packages
  • Offshore, seawater and desalination (duplex, CuNi, titanium)
  • Chemical process skids and module fabrication

Frequently asked questions

What are forged fittings?

Forged fittings are small-bore pipe fittings made from forged steel or alloy bar/billet, typically to ASME B16.11 for socket weld and threaded (screwed) ends in Class 2000, 3000, 6000 and 9000.

Socket weld vs threaded fittings?

Socket weld fittings are fillet-welded into a socket for permanent leak-tight joints. Threaded fittings screw onto NPT/BSPT pipe when welding is not preferred. Both follow ASME B16.11 dimensional rules.

Which pressure classes are common?

Class 3000 and Class 6000 are the most common; Class 9000 is used for thicker-wall / higher-pressure packages when specified.

What belongs on the purchase order?

Material grade / ASTM class, end type (SW or threaded), fitting form, size, pressure class, quantity, destination, and MTC (EN 10204 3.1 / 3.2). Email sales@savoypipinginc.com.

Quality Products

  • Quality Certified Materials
  • Marking, Heat Number, Specifications, Grade
  • Full Traceability of Material
  • Third Party Inspection / Buyer Inspection
  • NDT, Destructive Test Reports
  • Conformity to ASTM, ASME, DIN, EN, BS
  • Test Certificate as per EN 10204 3.1 / 3.2

Product Forms

Expertise

  • No Minimum Order
  • Material from Reputed Mills and Manufacturer
  • Products with Accurate Dimension
  • Abundant Stock, Immediate On-Time Delivery
  • 35 years of Supply and Export Experience
  • Sourcing even Hard to Find Items
  • Warranty and Guaranteed for Any Material Defect
