Stainless Steel, also known as inox steel, is a steel alloy with a minimum of 10.5 or 11% chromium content by mass.
Stainless steel Coil does not stain, corrode, or rust as easily as ordinary steel, but it is not stain-proof.
The term 'corrosion resistant steel' is used when the alloy has less than the 12% minimum of chromium, for example in the aviation industry. There are different grades and surface finishes of stainless steel, depending on where it will be used. Stainless steels have a higher resistance to oxidation (rust) and corrosion in many natural and man-made environments; however, it is important to select the correct type of stainless steel for the use. There are over 150 grades of stainless steel, of which fifteen are the most used.
An ISO 9001:2008 Certified Company, Savoy Piping Inc.,, is a leading Stockholder, Supplier and Exporter of ASTM A240 Stainless Steel Coil. Stainless Steel Coils are cut to your specifications and supplied with complete set of mill test reports. Custom length and width up to 2000 mm can be made available. Exports is Our Specialty! and we can source many hard to find grades and or non-standards sizes to meet the special requirements of our customers. All ASTM SS Steel Coil can be cut to size with the help of our extensive expertise in processing steel Coil products.
Our stock of Stainless Steel Coil includes thickness of 6mm up to 80mm with width of 1250mm, 1500mm, 2000mm.
Stainless Steel Coil Specification | ASTM A240 / ASME SA240 |
Stainless Steel Coil Manufacturing Process | Hot Rolled (HR) / Cold Rolled (CR) |
Stainless Steel Coil Grades | 202 / 304 / 304L / 304H / 309S / 310S / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc. UNS No. - UNS S30400, UNS S30403, UNS S31008, UNS S31620, UNS S31603, UNS S31603, UNS S31635, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904 EN No. - 1.4301, 1.4307, 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539 |
Stainless Steel Coil Thickness | 0.6 MM TO 80 MM THICKNESS |
Stainless Steel Coil Width | 1250 MM / 1500 MM / 2000 MM / 04 Feet / 05 Feet and Custom Cut Width as Per Requirement |
Stainless Steel Coil Length | 2400 MM / 2420 MM / 6000 MM / 08 Feet / 10 Feet / Coil Cut and Custom Cut Length as Per Requirement |
Stainless Steel Coil Surface Finish | 2B, 2D, BA, MATT, MATT PVC, No.4, No.5, SB, HR, No.8, Mirror, Hairline, Brush, Textured, Oil base wet Polished, Both sides Polished available. |
Stainless Steel Coil Coating | PVC coating Normal / Laser, Film: 100 micrometer, Color: black/white. |
Stainless Steel Coil Other Testing | NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, etc. |
Stainless Steel Coil Value Added Services | Gas Cutting / CNC Plasma Cutting / Profiling / Rolling / Bending / Sheet Metal Fabrication / Drill / Punch / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
Stainless Steel Coil Packaging | Loose / Carrate / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps |
Stainless Steel Coil Shipment & Transportation | By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
Stainless Steel Coil Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC |
The chemical composition of grade Stainless Steel is outlined in the following table
Designation | Chemical composition % by mass max unless stated | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
UNS No | SAE No | AISI No / Common Name | C | Si | Mn | P | S | Cr | Mo | Ni | Others |
S30100 | 30301 | 301 | 0.15 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | - | 6.0/8.0 | N 0.10 |
S30103 | - | 301L | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | - | 6.0/8.0 | N 0.20 |
S30153 | - | 301LN | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | - | 6.0/8.0 | N 0.07/0.20 |
S30200 | 30302 | 302 | 0.15 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | - | 8.0/10.0 | N 0.10 |
S30215 | 30302B | 302B | 0.15 | 2.00/3.00 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | - | 8.0/10.0 | - |
S30300 | 30303 | 303 | 0.15 | 1.00 | 2.00 | 0.20 | 0.15 min | 17.0/19.0 | - | 8.0/10.0 | |
S30310 | - | XM-5 (303Plus x) | 0.15 | 1.00 | 2.50/4.50 | 0.20 | 0.25 min | 17.00/19.00 | - | 7.00/9.00 | - |
S30323 | 30303Se | 303Se | 0.15 | 1.00 | 2.00 | 0.20 | 0.060 | 17.0/19.0 | - | 8.0/10.0 | Se 0.15 min |
S30330 | - | 303Cu | 0.15 | 1.00 | 2.00 | 0.15 | 0.10 min | 17.0/19.0 | - | 6.0/10.0 | Cu 2.5/4.0; Se 0.10 |
S30400 | 30304 | 304 | 0.07 | 0.75 | 2.00 | 0.045 | 0.030 | 17.5/19.5 | - | 8.0/10.5 | N 0.10 |
S30400 A276 for bar |
30304 | 304 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 8.0/11.0 | ||
S30403 | 30304L | 304L | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 17.5/19.5 | - | 8.0/12.0 | N 0.10 |
S30403 A276 for bar |
30304L | 304L | 0.030 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 8.0/12.0 | ||
S30430 | - | 302HQ | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | - | 8.0/10.0 | Cu 3.0/4.0 |
S30452 | - | XM-21 (304HN) | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | - | 8.00/10.00 | N 0.16/0.30 |
S30453 | - | 304LN | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | - | 8.0/12.0 | N 0.10/0.16 |
S30454 | - | - | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | - | 8.0/11.0 | N 0.16/0.30 |
S30500 | 30305 | 305 | 0.12 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | - | 10.5/13.0 | - |
S30800 | 30308 | 308 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 19.0/21.0 | - | 10.0/12.0 | - |
S31600 | 30316 | 316 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | N 0.10 |
S31603 | 30316L | 316L | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | N 0.10 |
S31635 | - | 316Ti | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 |
Ti 5x (C+N) / 0.70 N 0.10 |
S31640 | - | 316Cb | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 |
Nb 10x C / 1.10 N 0.10 |
S31653 | - | 316LN | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | N 0.10/0.16 |
S31700 | 30317 | 317 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 3.0/4.0 | 11.0/15.0 | N 0.10 |
S31703 | - | 317L | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 3.00/4.00 | 11.0/15.0 | N 0.10 |
S31725 | - | 317LM | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 4.0/5.0 | 13.5/17.5 | N 0.20 |
S31726 | - | 317LMN | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/20.0 | 4.0/5.0 | 13.5/17.5 | N 0.10/0.20 |
S31753 | - | 317LN | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 3.0/4.0 | 11.0/15.0 | N 0.10/0.22 |
S32100 | 30321 | 321 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | - | 9.0/12.0 |
Ti 5 x C min/0.70 N 0.10 |
S34700 | 30347 | 347 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | - | 9.0/13.0 | Nb+Ta 10 x C min/1.0 |
S34720 | - | 347F | 0.08 | 1.00 | 2.00 | 0.040 | 0.18/0.35 | 17.00/19.00 | 0.75 | 9.00/12.00 | Nb 10xC / 1.10; Cu 0.75; Ta 0.05 |
S34723 | - | 347FSe | 0.08 | 1.00 | 2.00 | 0.11/0.17 | 0.030 | 17.00/19.00 | 0.75 | 9.00/12.00 | Nb 10xC / 1.10; Cu 0.75; Se 0.15/0.35; Ta 0.05 |
S34800 | 30348 | 348 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | - | 9.00/13.0 | Nb+Ta 10 x C / 1.00; Ta:0.10 max; Co 0.20 |
S38400 | 30384 | 384 | 0.04 | 1.00 | 2.00 | 0.045 | 0.030 | 15.0/17.0 | - | 17.0/19.0 | - |
The mechanical properties of grade Stainless Steel Coil are displayed in the following table.
S.S. | 200 | 202 | 301 | 302 | 303 | 304 | 304L | 309 | 309s | 310 | 310s | 314 | 316 | 316L | 317 | 321 | 347 |
Tensile Strength |
105 | 105 | 110 | 90 | 90 | 85 | 60 | 90 | 90 | 95 | 95 | 100 | 85 | 78 | 90 | 87 | 92 |
Yield Strength |
55 | 55 | 40 | 37 | 35 | 35 | 30 | 40 | 40 | 40 | 40 | 50 | 35 | 30 | 40 | 35 | 35 |
Elongation in 2' |
55 | 55 | 60 | 55 | 50 | 55 | 55 | 45 | 45 | 45 | 45 | 45 | 55 | 55 | 50 | 55 | 50 |
Rockwell | 90 | 90 | 85 | 82 | 84 | 80 | 76 | 85 | 85 | 87 | 87 | 87 | 80 | 76 | 85 | 80 | 84 |
Brinell | 185 | 185 | 165 | 155 | 160 | 150 | 140 | 165 | 165 | 170 | 170 | 170 | 150 | 145 | 160 | 150 | 160 |
En58M | En58E | En58J&H | En58C | ||||||||||||||
X12 CrNi17.7 |
X2 CrNi18.8 |
X5 CrNi18.9 |
X5 CrNi18.8 |
x5 CrNiMo18.12 |
X2 CrNiMo19.1 |
X10 CrNiMo18.9 |
|||||||||||
AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. |
S.S.Grade | 201 | 202 | 301 | 302 | 304 | 304L | 309 | 309S | 310 | 310S | 316 | 316L | 321 | 347 | 409 | 430 | 434 | 410 |
Density | 7.9 | 7.9 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 7.7 | 7.8 | 7.8 | 7.8 |
Sp.Elec. Resist 20C micro | 72 | 72 | 72 | 72 | 72 | 72 | 78 | 78 | 78 | 78 | 74 | 74 | 72 | 73 | 60 | 60 | 60 | 57 |
Sp. Heat (0-100c) | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 46 | 46 | 46 | 46 |
Ther. Conductivity | 16.3 | 16.3 | 16.3 | 16.3 | 16.3 | 16.3 | 14.2 | 14.2 | 14.2 | 14.2 | 16.3 | 16.3 | 16.3 | 16.3 | 25.1 | 26.0 | 26.0 | 25.1 |
15.7 | 18.4 | 17.0 | 17.2 | 17.3 | 17.3 | 15.0 | 15.0 | 15.9 | 15.9 | 15.9 | 15.9 | 16.6 | 16.6 | 11.7 | 10.4 | 11.9 | 9.9 | |
Mild water | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X |
Industrial | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | ||
Marine | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | |||
Salt Water | X | X | ||||||||||||||||
Mild | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X |
Oxidising | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | ||
Reducing | X | X | ||||||||||||||||
Abrasion Resistance | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good |
Cold Forming | Fair | Good | Good | Excel | Excel | Good | Good | Good | Good | Good | Good | Good | Good | Good | Fair | Fair | Fair | Fair |
Weldability | Good | Good | Excel | Excel | Excel | Excel | Good | Excel | Good | Excel | Excel | Excel | Excel | Excel | Fair | Fair | Fair | Fair |
Melting Flange | 1400 1420 | 1400 1450 | 1370 1400 | 1400 1430 | 1430 1510 | 1480 1530 | ||||||||||||
Scaling Temp | 800 | 800 | 800 | 900 | 900 | 900 | 1100 | 1100 | 1100 | 1100 | 900 | 900 | 900 | 900 | 700 | 800 | 800 | 700 |
