Chequered Plate, also known as Checker Plate, Tread Plate, Diamond Plate and Durbar Floor Plate, is a type of metal stock with a regular Pattern of raised Diamonds or lines on one side, with the reverse side being featureless.
Chequered Plate is usually Steel, Stainless steel or Aluminum. Steel types are normally made by hot rolling, although modern manufacturers also make a raised and pressed diamond design.
The added Texture reduces the risk of slipping, making diamond plate a solution for stairs, catwalks, walkways, and ramps in industrial settings. Its non-skid properties mean that diamond plate is frequently used on the interior of ambulances and on the footplates of firetrucks. Additional applications include truck beds and trailer floors.
Chequered plate can also be used decoratively, particularly highly polished aluminum variants. Manufactured in plastic, diamond plate is marketed as an interlocking tile system to be installed on garage floors, trailers, and exercise rooms.
Stainless Steel Chequered Plate may be used for surface protection against damage from foot traffic or harmful chemicals. Manufactured with polymer variants, inter-locking diamond plate tile is used in areas with high surface-erosive traffic.
Stainless Steel, also known as inox steel, is a steel alloy with a minimum of 10.5 or 11% chromium content by mass.
Stainless steel Plate does not stain, corrode, or rust as easily as ordinary steel, but it is not stain-proof.
The term 'corrosion resistant steel' is used when the alloy has less than the 12% minimum of chromium, for example in the aviation industry. There are different grades and surface finishes of stainless steel, depending on where it will be used. Stainless steels have a higher resistance to oxidation (rust) and corrosion in many natural and man-made environments; however, it is important to select the correct type of stainless steel for the use. There are over 150 grades of stainless steel, of which fifteen are the most used.
An ISO 9001:2008 Certified Company, Savoy Piping Inc.,, is a leading Stockholder, Supplier and Exporter of ASTM A240 Stainless Steel Chequered Plate. Stainless Steel Plates are cut to your specifications and supplied with complete set of mill test reports. Custom length and width up to 2000 mm can be made available. Exports is Our Specialty! and we can source many hard to find grades and or non-standards sizes to meet the special requirements of our customers. All ASTM SS Chequered Plate can be cut to size with the help of our extensive expertise in processing steel Plate products.
Our stock of Stainless Steel Chequered Plate includes thickness of 6mm up to 80mm with width of 1250mm, 1500mm, 2000mm.
Stainless Steel Chequered Plate Specification | ASTM A240 / ASME SA240 |
Stainless Steel Chequered Plate Manufacturing Process | Hot Rolled (HR) / Cold Rolled (CR) |
Stainless Steel Chequered Plate Grades | 202 / 304 / 304L / 304H / 309S / 310S / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc. UNS No. - UNS S30400, UNS S30403, UNS S31008, UNS S31620, UNS S31603, UNS S31603, UNS S31635, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904 EN No. - 1.4301, 1.4307, 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539 |
Stainless Steel Chequered Plate Thickness | 0.6 MM TO 80 MM THICKNESS |
Stainless Steel Chequered Plate Width | 1250 MM / 1500 MM / 2000 MM / 04 Feet / 05 Feet and Custom Cut Width as Per Requirement |
Stainless Steel Chequered Plate Length | 2400 MM / 2420 MM / 6000 MM / 08 Feet / 10 Feet / Coil Cut and Custom Cut Length as Per Requirement |
Stainless Steel Chequered Plate Surface Finish | 2B, 2D, BA, MATT, MATT PVC, No.4, No.5, SB, HR, No.8, Mirror, Hairline, Brush, Textured, Oil base wet Polished, Both sides Polished available. |
Stainless Steel Chequered Plate Coating | PVC coating Normal / Laser, Film: 100 micrometer, Color: black/white. |
Stainless Steel Chequered Plate Other Testing | NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, etc. |
Stainless Steel Chequered Plate Value Added Services | Gas Cutting / CNC Plasma Cutting / Profiling / Rolling / Bending / Sheet Metal Fabrication / Drill / Punch / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
Stainless Steel Chequered Plate Packaging | Loose / Carrate / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps |
Stainless Steel Chequered Plate Shipment & Transportation | By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
Stainless Steel Chequered Plate Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC |
The chemical composition of grade Stainless Steel is outlined in the following table
Designation | Chemical composition % by mass max unless stated | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
UNS No | SAE No | AISI No / Common Name | C | Si | Mn | P | S | Cr | Mo | Ni | Others |
S30400 | 30304 | 304 | 0.07 | 0.75 | 2.00 | 0.045 | 0.030 | 17.5/19.5 | - | 8.0/10.5 | N 0.10 |
S30403 | 30304L | 304L | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 17.5/19.5 | - | 8.0/12.0 | N 0.10 |
S31600 | 30316 | 316 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | N 0.10 |
S31603 | 30316L | 316L | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | N 0.10 |
The mechanical properties of grade Stainless Steel Plates are displayed in the following table.
S.S. | 304 | 304L | 316 | 316L |
Tensile Strength | 85 | 60 | 85 | 78 |
Yield Strength | 35 | 30 | 35 | 30 |
Elongation in 2' | 55 | 55 | 55 | 55 |
Rockwell | 80 | 76 | 80 | 76 |
Brinell | 150 | 140 | 150 | 145 |
En58J&H | ||||
X5 CrNi18.9 |
X5 CrNi18.8 |
x5 CrNiMo18.12 |
X2 CrNiMo19.1 |
|
AUST. | AUST. | AUST. | AUST. |
S.S.Grade | 304 | 304L | 316 | 316L |
Density | 8.0 | 8.0 | 8.0 | 8.0 |
Sp.Elec. Resist 20C micro | 72 | 72 | 74 | 74 |
Sp. Heat (0-100c) | 0.5 | 0.5 | 0.5 | 0.5 |
Ther. Conductivity | 16.3 | 16.3 | 16.3 | 16.3 |
17.3 | 17.3 | 15.9 | 15.9 | |
Mild water | X | X | X | X |
Industrial | X | X | X | X |
Marine | X | X | X | X |
Salt Water | X | |||
Mild | X | X | X | X |
Oxidising | X | X | X | X |
Reducing | X | X | ||
Abrasion Resistance | Good | Good | Good | Good |
Cold Forming | Excel | Good | Good | Good |
Weldability | Excel | Excel | Excel | Excel |
Melting Flange | 1430 1510 | 1480 1530 | ||
Scaling Temp | 900 | 900 | 900 | 900 |
Buy Now Stainless Steel Chequered Plate at an Attactive Discounted Price, Order Above USD $ 25000 are Eligible of 2% Discount. We Offer Free Insurance and Best Shipping Rates. Our Prices are Always More Competitive and without any compromise in Quality of the Material.
