Savoy Piping Inc. supplies API 5L PSL2 welded SAW line pipe across the commercial grade range for oil and gas pipeline transportation.
PSL2 orders need toughness, tighter chemistry and fuller documentation — quote the complete test package up front.
Related: API 5L Welded LSAW / DSAW / HSAW Hub, PSL1 Seamless Hub.
Expect carbon equivalent controls, CVN impact, yield/tensile caps and more rigorous NDE versus PSL1.
Also see: API 5L seamless line pipe hub · Carbon seamless hub · CS buttweld.
Grade B, X42, X46, X52, X56, X60, X65, X70 — confirm delivery condition (especially PSL2 R/N/Q/M), OD/wall and annex testing on every enquiry.
| API 5L PSL2 Welded Pipe Piping Specification | API 5L / ISO 3183 Hot Rolled. |
| API 5L PSL2 Welded Pipe Grades | API 5L Grade B PSL1, PSL 2 / API 5L X42 PSL1, PSL 2 / API 5CT / API 5L X46 PSL1, PSL 2 / API 5L X52 PSL1, PSL 2 / API 5L X56 PSL1, PSL 2 / API 5L X60 PSL1, PSL 2 / API 5L X65 PSL1, PSL 2 / X70 PSL1, PSL 2 / API 5L X70 PSL1 / PSL2 / API 5L X80 PSL1, PSL 2 / ISO 3183 L245 PSL1, PSL 2, ISO 3183 L290 PSL1, PSL 2, ISO 3183 L320 PSL1, PSL2, ISO 3183 L360 PSL1, PSL 2, ISO 3183 L390 PSL1, PSL 2, ISO 3183 L415 PSL1, PSL 2, ISO 3183 L450 PSL1, PSL 2, ISO 3183 L485 PSL1, PSL 2 |
| API 5L PSL2 Welded Pipe Type | Seamless |
| API 5L PSL 1 Welded Pipe Outer Diameter Size | 3/8" NB to 30" NB (Nominal Bore Size) |
| API 5L PSL2 Welded Pipe Wall Thickness | Schedule 20 to Schedule XXS (Heavier On Request) Up to 250 mm Thickness |
| API 5L PSL2 Welded Pipe Length | 5 to 7 Meters, 09 to 13 Meters, Single Random Length, Double Random Length And Customize Size. |
| API 5L PSL2 Welded Pipe Ends | Plain Ends / Beveled Ends / Coupling |
| API 5L PSL2 Welded Pipe Delivery Conditions | As Rolled, Normalizing Rolled, Thermomechanical Rolled / Formed, Normalizing Formed, Normalized and Tempered / Quenched and Tempered - BR / N / Q /T |
| API 5L PSL2 Welded Pipe Coating | Epoxy Coating / Colour Paint Coating / 3LPE Coating. |
| API 5L PSL2 Welded Pipe Other Testing | NACE MR0175, NACE TM0177, SOUR SERVICE, NACE TM0284, PWHT, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, IPS-M-PI19, IPS-M-PI-221 APPENDIX G Etc. |
| API 5L PSL2 Welded Pipe Dimension | All Pipes Tube Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, API. |
| API 5L PSL2 Welded Pipe Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment |
| API 5L PSL2 Welded Pipe Packaging | Loose / Bundle / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| API 5L PSL 1 Welded Pipe Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet |
| API 5L PSL2 Welded Pipe Material Test Certificate | Manufacturer Test certificate As Per EN10204 3.1, 3.2 / Laboratory Test certificate From NABL Approved Lab./ Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| API 5L PSL2 Welded Pipe Specification | API 5L / ISO 3183 Hot Rolled. |
| API 5L PSL2 Welded Pipe Grades | API 5L Grade B PSL1, PSL 2 / API 5L X42 PSL1, PSL 2 / API 5L X46 PSL1, PSL 2 / API 5L X52 PSL1, PSL 2 / API 5L X56 PSL1, PSL 2 / API 5L X60 PSL1, PSL 2 / API 5L X65 PSL1, PSL 2 / X70 PSL1, PSL 2 / API 5L X70 PSL1 / PSL2 / API 5L X80 PSL1, PSL 2 / ISO 3183 L245 PSL1, PSL 2, ISO 3183 L290 PSL1, PSL 2, ISO 3183 L320 PSL1, PSL2, ISO 3183 L360 PSL1, PSL 2, ISO 3183 L390 PSL1, PSL 2, ISO 3183 L415 PSL1, PSL 2, ISO 3183 L450 PSL1, PSL 2, ISO 3183 L485 PSL1, PSL 2 |
| API 5L PSL2 Welded Pipe Type | Seamless |
| API 5L PSL 1 Welded Pipe Outer Diameter Size | 3/8" NB to 30" NB (Nominal Bore Size) |
| API 5L PSL2 Welded Pipe Wall Thickness | Schedule 20 to Schedule XXS (Heavier On Request) Up to 250 mm Thickness |
| API 5L PSL2 Welded Pipe Length | 5 to 7 Meters, 09 to 13 Meters, Single Random Length, Double Random Length And Customize Size. |
| API 5L PSL2 Welded Pipe Ends | Plain Ends / Beveled Ends / Coupling |
| API 5L PSL2 Welded Pipe Delivery Conditions | As Rolled, Normalizing Rolled, Thermomechanical Rolled / Formed, Normalizing Formed, Normalized and Tempered / Quenched and Tempered - BR / N / Q /T |
| API 5L PSL2 Welded Pipe Coating | Epoxy Coating / Colour Paint Coating / 3LPE Coating. |
| API 5L PSL2 Welded Pipe Other Testing | NACE MR0175, NACE TM0177, SOUR SERVICE, NACE TM0284, PWHT, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, IPS-M-PI19, IPS-M-PI-221 APPENDIX G Etc. |
| API 5L PSL2 Welded Pipe Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, API. |
| API 5L PSL2 Welded Pipe Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment |
| API 5L PSL2 Welded Pipe Packaging | Loose / Bundle / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| API 5L PSL 1 Welded Pipe Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet |
| API 5L PSL2 Welded Pipe Material Test Certificate | Manufacturer Test certificate As Per EN10204 3.1, 3.2 / Laboratory Test certificate From NABL Approved Lab./ Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| PSL 1 | |||||||||
| Grade | Chemical Composition | Mechanical Property | |||||||
| C (Max) | Mn (Max) | P (Max) | S (Max) | TENSILE ( Min) | YIELD ( Min) | ||||
| Psi X 1000 | Mpa | Psi X 1000 | Mpa | ||||||
| A25 | CL I | 0.21 | 0.60 | 0.030 | 0.030 | 4 | 310 | 25 | 172 |
| CL II | 0.21 | 0.60 | 0.030 | 0.030 | |||||
| A | 0.22 | 0.9 | 0.030 | 0.030 | 48 | 331 | 30 | 207 | |
| B | 0.26 | 1.20 | 0.030 | 0.030 | 60 | 414 | 35 | 241 | |
| X42 | 0.26 | 1.30 | 0.030 | 0.030 | 60 | 414 | 42 | 29 | |
| X46 | 0.26 | 1.40 | 0.030 | 0.030 | 63 | 434 | 46 | 317 | |
| X52 | 0.26 | 1.40 | 0.030 | 0.030 | 66 | 45 | 52 | 359 | |
| X56 | 0.26 | 1.40 | 0.030 | 0.030 | 71 | 49 | 56 | 386 | |
| X60 | 0.26 | 1.40 | 0.030 | 0.030 | 75 | 517 | 60 | 414 | |
| X65 | 0.26 | 1.4 | 0.030 | 0.030 | 77 | 531 | 65 | 448 | |
| X70 | 0.26 | 1.65 | 0.030 | 0.030 | 82 | 565 | 70 | 483 | |
The information here is summarized from ASTM Standards and API Specification 5L. Please see the specific API Standards for more information.
| Grade Range | A25 Through X70 | Gr B Through X80 | Table 1 |
| Size Range | 0.405 Through 80 | 4-2/1 Through 80 | Table 1 |
| Type Of Pipe Ends | Plain-End, Threaded-end, Bevelled-End, Special Coupling Pipe | Plain-End | Table 1 |
| Seam Welding | All Methods Continous Welding Limited to Grade A25 | All Methods Except Continous And Laser Welding | Table 1 |
| Electric Welds: Welder Frequency | No Minimum | 100 Khz Minimum | 5.1.3.3.2 |
| Heat Treatments of Electric Welds | Required For Grades > X42 | Required For All Grades (Gr B Through X80) | 5.1.3.3.1; J.3.3.2:6.2.7 |
| Chemistry: Max C For Seamless Pipe | 0.28% For Grades > Gr B | 0.24% | tables 2a, 2b |
| Chemistry: Max C For Welded Pipe | 0.26% For Grades > Gr B | 0.22% | tables 2a, 2b |
| Chemistry: Max P | 0.03% | 0.03% | Tables 2a, 2b |
| Chemistry: Max S | Only When Purchases Specifies Sr18 | 0.02% | Tables 2a, 2b |
| Carbon Steel Equivalent | None | Maximum Required for Each Grade | 4.2:4.3:6.1.3: Sr15.1 |
| Yield Strength, Maximum | None | Maximum for Each Grade | tables 3a, 3b |
| UTS, Maximum | None Required | Maximum For Each Grade | Tables 3a, 3b |
| Fracture Toughness | Only When Purchaser Specifies Sr4 | Required For All Grades | 6.2.6; 9.3.5: 9.8.4; 9.10.7; |
| Non-destructive Inspection of Seamless Pipes | Permitted | sr4 Mandatory | table 14 9.7.2.6 |
| Repair By Welding of Pipe Body, Plate And Skelp | Permitted By Agreement | Prohibited | 5.3.2;9.7.6: B.1;b.2 |
| Certification | certificates When Specified Per Sr15 | Prohibited | 4.3;9.7.4.4;9.7.6;b.1.2;b.4 |
| Traceability | Traceable Only Until All Tests are Passed Unless Sr15 Is Specified | certificates (Sr15.1) Mandatory Traceable After Completion of Tests (Sr15.2) Mandatory |
12.1 5.6 |
| Country Name | Latest Price/ Recent Updated Price 2017-18 |
| API 5L PSL1 Pipe Price in Indonesia | US $850 - 950 / Metric Ton |
| API 5L PSL1 Pipe Price in Malaysia | US $850 - 99 / Metric Ton |
| API 5L PSL1 Pipe Price in United Arab Emirates | AED 3121.84 - 3489.11/ Metric Ton |
| API 5L PSL1 Pipe Price in Singapore | US $850 - 995 / Metric Ton |
| API 5L PSL1 Pipe Price in Iran | US $850 - 950 / Metric Ton |
| API 5L PSL1 Pipe Price in South Korea | US $850 - 1350 / Metric Ton |
| API 5L PSL1 Pipe Price in Egypt | US $850 - 1150 / Metric Ton |
| API 5L PSL1 Pipe Price in Saudi Arabia | US $850 - 950 / Metric Ton |
| API 5L PSL1 Pipe Price in Kuwait | US $850 - 950 / Metric Ton |
| API 5L PSL1 Pipe Price in South Africa | US $850 - 1100 / Metric Ton |
| API 5L PSL1 Pipe Price in Qatar | US $850 - 950 / Metric Ton |
| API 5L PSL1 Pipe Price in Bahrain | BD 320-358 / Metric Ton |
| API 5L PSL1 Pipe Price in Oman | US $850 - 950 / Metric Ton |
| API 5L PSL1 Pipe Price in India | INR 56988-63692/ Metric Ton |
| API 5L PSL1 Pipe Price in Taiwan | US $850 - 950 / Metric Ton |
| API 5L PSL1 Pipe Price in Vietnam | US $850 - 1250 / Metric Ton |
| API 5L PSL1 Pipe Price in USA | US $850 - 1050 / Metric Ton |
CHEMICAL REQUIREMENTS for API 5L x42 PSL2 steel Pipe
CHEMICAL REQUIREMENTS for API 5L PSL2 welded steel Pipe
API 5L Specifications Covers Seamless and Welded pipe suitable for use in conveying Shale Gas, water, Oil Sands, and other liquefied media such as Ethanol and Gasoline The attached requirements cover our offering of API 5L 4th Ed, PSL 1Seamless and Welded; API 5L 4th Ed PSL 2 Seamless & Welded; and API 5L 4th Ed PSL2 Welded only.
TENSILE PROPERTIES for Seamless and Welded API 5L PSL2 steel Pipe
tensile properties data for Seamless and Welded API 5L Steel Pipe API 5L 4th Ed PSL 1, PSL 2.
TESTING REQUIREMENTS for Seamless and Welded API 5L PSL2 steel Pipe
Our API 5L Seamless Pipe hydrostatic and mechanical testing information for all sizes and grades covered by the specification.
Permissible Variations for Seamless and Welded API 5L PSL2 steel Pipe
| Grade A, B, A25 | X42 through X80 | |
| NPS 2-1/2 and smaller --Seamless and Welded, % | +20 -- 12.5 | +15 -- 12.5 |
| NPS 3 --Seamless and Welded, % | +18 -- 12.5 | +15 -- 12.5 |
| NPS 4 through 18 --Seamless and Welded, % | +15 -- 12.5 | +15 -- 12.5 |
| NPS 20 and larger -- Welded, % | +17.5 -- 10.0 | +19.5 -- 8.0 |
| NPS 20 and larger -- Seamless, % | +15.0 -- 12.5 | +17.5 -- 10.0 |
Marking Requirements
Paint-stenciled or die-stamped manufacturer’s name or mark, Spec 5L, size, weight per foot, grade, process of manufacture, type of Stainless Steel, length (NPS 4 and larger only). Test pressure when higher than tabulated (NPS 2 and larger only).
Supplemental Annexes for API 5L PSL2Seamless and Welded steel Pipe
API Specification 5L contains 15 Supplemental Annexes that address special conditions and/or additional requirements.
 Sabic Saudi Arabia) |
 Shell |
 ALBA (Saudi Arabia) |
 QAFCO(Qatar) |
 Maaden(Saudi Arabia) |
 KNPC(Kuwait) |
 Kuwait Oil Refinery Company(Kuwait) |
 Qatar Petroleum(Qatar) |
 Petroleum Development Oman(Oman) |
 ADNOC(United Arab Emirates) |
 Orpic(Oman) |
 Takreer(Abu Dhabi) |
 YASREF(Abu Dhabi) |
 Petrobras(Brazil) |
 Petronas(Malaysia) |
 NIOC(Iran) |
 NPDC(Nigeria) |
 Egyptian General petroleum Corporation(Egypt) |
PSL2 is the higher product specification level in API 5L — tighter chemistry, toughness and more testing than PSL1.
Commercial supply typically covers Grade B, X42, X46, X52, X56, X60, X65 and X70 under the ordered PSL.
This hub focuses on welded LSAW/DSAW/HSAW product form. Twin PSL pages cover the other construction.
Yes when testing meets both specs — state dual certification on the PO.
We Export API 5L PSL2 Welded Pipe to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen, Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Myanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States of America, Canada, Mexico, Panama, Costa Rica, Puerto Rico, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherlands, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East.etc
Savoy Piping Inc. is a well known worldwide exporter of API 5L PSL2 Welded Pipe is committed to provide each and every customer with the highest standard of customer service. We deal in API 5L PSL2 Welded Pipe in India and Overseas, offering a wide range of API 5L PSL 1 Welded Line Pipes
