API 5L Welded Pipes - API 5L X60 PSL1 Welded Line Pipes (SAW Pipes ), API 5L X60 PSL1 Welded Pipes, API 5L X60 PSL1 Welded Line Pipes, API 5L X60 PSL1 Carbon Steel Welded Pipes, API 5L X60 PSL1 SAW Pipes, API 5L X60 PSL1 LSAW Pipes, API 5L X60 PSL2 DSAW Pipes, API 5L X60 PSL1 HSAW Pipes .
API 5L X60 PSL1 Welded Pipes Certified and Tested in accordance with ISO 3183, ISO 15156, NACE MRO175 / 103, HIC, SWC, SSC, SSCC, SOUR Service, H2S, IMPACT, Post Weld Heat Treatment (PWHT), IBR, High yield, IPS-M-PI-190, IPS-M-PI-221 etc.
Savoy Piping Inc. we carry a full inventory of API 5L Pipe Carbon Steel Pipe Steel Products in a variety of sizes to meet the structural piping requirements for applications the water, petroleum, oil & gas and other industries. API 5L X60 PSL1 Welded Pipe Carbon Steel Pipe can be Structural in Nature or used in Fluid, Gas, Oil Transmission.
We Supply API 5L Welded Line Pipe in API 5L Grade B PSL 1 Welded Pipe
API 5L Grade B PSL 2 Welded Pipe, API 5L Grade X42 PSL 1 Welded Pipe, API 5L Grade X42 PSL 2 Welded Pipe, API 5L Grade X46 PSL 1 Welded Pipe, API 5L Grade X46 PSL 2 Welded Pipe, API 5L Grade X52 PSL 1 Welded Pipe, API 5L Grade X52 PSL 2 Welded Pipe, API 5L Grade X56 PSL 1 Welded Pipe,API 5L Grade X56 PSL 2 Welded Pipe,API 5L Grade X60 PSL 1 Welded Pipe, API 5L Grade X60 PSL 2 Welded Pipe, API 5L Grade X65 PSL 1 Welded Pipe, API 5L Grade X65 PSL 2 Welded Pipe, API 5L Grade X70 PSL 1 Welded Pipe, API 5L Grade X70 PSL 2 Welded Pipe The grade indicates the testing methods required for a given application. It is critical that structural grades of Carbon Steel Pipe not be used for Pressure or Fluid applications.
Savoy Piping Inc.specializes in API 5L X60 PSL1 Welded Line Pipe with years of Experience in Manufacturing API 5L X60 PSL1 Carbon Steel Welded Pipe we offer high quality, lower cost but the best service. As a result to that our API 5L X60 PSL1 Welded LSAW Pipes export account today is in various countries like Iran, Iraq, Kuwait, Saudi Arabia, Oman, UAE, Singapore, Malaysia, Indonesia, South korea, Chile, Peru, Venezuela, Australia, Nigeria, Angola, Senegal, Mozambique, Algeria, Libya, Azerbaijan, Netherlands, Brazil, Norway, United Kingdom, Mexico, Canada etc.
Introduction of API 5L X60 PSL1 Welded Pipes (LSAW / DSAW / HSAW)
These pipes are manufactured in two product specification levels known as PSL-1 and PSL-2. PSL-1 provides standard level quality as a linepipe. However, PSL-2 pipe has additional chemical composition, mechanical properties, notch toughness, and additional NDT requirements.
API 5L X60 Pipe Specification Covers Seamless and Welded Steel Line Pipe. It includes standard-weight and Extra-Strong threaded Line Pipe. It includes standard-weight and extra-strong threaded line pipe; and standard-weight plain-end, regular-weight plain-end, special plain-end, extra-strong plain-end, special plain-end, extra-strong plain-end pipe; as as well as bell and spigot and through-the-flow line(TFL) pipe. The purpose of this specification is to provide standards for pipe suitable for use in conveying gas, water, and oil in both the oil and natural gas industries Grades covered by this specification are A25 ,A ,B (and the following "X" Grades) X42, X46, X52, X60, X65, & X70 The two digit number following the "X" indicates the Minimum Yield Strength (in 000's psi) of pipe produced to this grade.
API 5L X60 PSL1 Electric Welded Pipe
If the grade is higher than that, it will be replaced. If such substitution is made, the manufacturer must demonstrate the effectiveness of the chosen method using mutually agreed upon procedures. These steps include, but are not necessarily limited to, hardness testing, microstructural evaluation, and mechanical testing. Welded seams for grades below API 5L X60 The pipe must be similarly heat treated or machined so that no unhardened martensite remains.
API 5L Standard:
The American Petroleum Institute (API) establishes standards for the oil and gas industry. API 5L is a specification that defines requirements for the manufacturing of two product specification levels (PSL1 and PSL2) of seamless and welded steel pipes suitable for use in pipeline transportation systems.
X60 Grade:
"X60" denotes the minimum yield strength of the steel in thousands of pounds per square inch. In this case, the minimum yield strength is 60,000 psi. The X60 grade is commonly used in various applications, particularly in the oil and gas industry.
PSL1 (Product Specification Level 1):
PSL1 is a quality level defined in the API 5L standard. Pipes classified under PSL1 have lower requirements compared to PSL2. PSL1 pipes are known for their basic manufacturing and testing processes, making them suitable for less critical applications.
Welded Pipes (LSAW / DSAW / HSAW):
These pipes are manufactured using different welding processes, each with specific characteristics:
- LSAW (Longitudinal Submerged Arc Welding): Welding occurs along the length of the pipe using a submerged arc welding process.
- DSAW (Double Submerged Arc Welding): Similar to LSAW, but the welding is done on both the inner and outer surfaces simultaneously.
- HSAW (Helical Submerged Arc Welding): Welding is performed in a helical pattern, resulting in a spiral-welded pipe.
API 5L X60 PSL1 Welded Pipes are steel pipes with a specified grade (X60) and quality level (PSL1) according to the API 5L standard. They are produced using various welding techniques (LSAW, DSAW, HSAW) and are commonly employed in the transportation of fluids, especially in the oil and gas industry.
our API 5L X60 PSL1 Welded Line Pipe range
| API 5L X60 PSL1 Welded Pipe Specification | API 5L / ISO 3183 Hot Rolled. |
| API 5L X60 PSL1 Welded Pipe Grades | API 5L Grade B PSL1, PSL 2 / API 5L X42 PSL1, PSL 2 / API 5L X46 PSL1, PSL 2 / API 5L X52 PSL1, PSL 2 / API 5L X56 PSL1, PSL 2 / API 5L X60 PSL1, PSL 2 / API 5L X65 PSL1, PSL 2 / X70 PSL1, PSL 2 / API 5L X70 PSL1 / PSL2 /API 5CT / API 5L X80 PSL1, PSL 2 / ISO 3183 L245 PSL1, PSL 2, ISO 3183 L290 PSL1, PSL 2, ISO 3183 L320 PSL1, PSL2, ISO 3183 L360 PSL1, PSL 2, ISO 3183 L390 PSL1, PSL 2, ISO 3183 L415 PSL1, PSL 2, ISO 3183 L450 PSL1, PSL 2, ISO 3183 L485 PSL1, PSL 2 |
| API 5L X60 PSL1 Welded Pipe Type |
LSAW Pipes (Longitudinal Submerged Arc Welded Pipes ) HSAW Pipes (Helical Submerged Arc Welded Pipes ) DSAW Pipes (Double Submerged Arc Welded Pipes ) HSAW Pipes (Helical Submerged Arc Welded Pipes ) SSAW Pipes (Spiral Submerged Arc Welded Pipes ) |
| API 5L X60 PSL1 Welded Pipe Outer Diameter Size | 12" NB to 150" NB (Nominal Bore Size) |
| API 5L X60 PSL1 Welded Pipe Wall Thickness | Schedule 20 to Schedule XXS (Heavier On Request) Up to 250 mm Thickness |
| API 5L X60 PSL1 Welded Pipe Length | 5 to 7 Meters, 09 to 13 Meters, Single Random Length, Double Random Length And Customize Size. |
| API 5L X60 PSL1 Welded Pipe Ends | Plain Ends / Beveled Ends / Coupling |
| API 5L X60 PSL1 Welded Pipe Delivery Conditions | As Rolled, Normalizing Rolled, Thermomechanical Rolled / Formed, Normalizing Formed, Normalized and Tempered / Quenched and Tempered - BR / N / Q /T |
| API 5L X60 PSL1 Welded Pipe Coating | Epoxy Coating / Colour Paint Coating / 3LPE Coating. |
| API 5L X60 PSL1 Welded Pipe Other Testing | NACE MR0175, NACE TM0177, SOUR SERVICE, NACE TM0284, PWHT, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, IPS-M-PI190, IPS-M-PI-221 APPENDIX G Etc. |
| API 5L X60 PSL1 Welded Pipe Dimension | All Pipes Tube Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, API. |
| API 5L X60 PSL1 Welded Pipe Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment |
| API 5L X60 PSL1 Welded Pipe Packaging | Loose / Bundle / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| API 5L X60 PSL1 Welded Pipe Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet |
| API 5L X60 PSL1 Welded Pipe Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab./ Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
API 5L X60 Welded Line Pipes PSL 1 Chemical Composition
| Mass Fraction, based upon heat and product analyses | ||||||||
| Steel grade | C | Mn | P | S | V | NB | Ti | |
| (Steel name) | max | max. | min. | max. | max. | max. | max. | max. |
| L175 or A25 | 0.21 | 0.60 | 0.030 | 0.030 | - | |||
| L175P or A25P | 0.21 | 0.60 | 0.045 | 0.800 | 0.030 | |||
| L210 or A | 0.22 | 0.90 | - | 0.030 | 0.030 | - | - | - |
| L245 or B | 0.26 | 1.20 | 0.030 | 0.030 | c,d | c,d | d | |
| L290 or X42 | 0.26 | 1.30 | 0.030 | 0.030 | d | d | d | |
| L320 or X46 | 0.26 | 1.40 | - | 0.030 | 0.030 | d | d | d |
| L360 or X52 | 0.26 | 1.40 | 0.030 | 0.030 | d | d | d | |
| L390 or X56 | 0.26 | 1.40 | 0.030 | 0.030 | d | d | d | |
| L415 or X60 | 0.26 | 1.40 | - | 0.030 | 0.030 | f | f | f |
| L450 or X65 | 0.26 | 1.45 | 0.030 | 0.030 | f | f | f | |
| L485 or X70 | 0.26 | 1.65 | 0.030 | 0.030 | f | f | f | |
API 5L X60 Welded Line Pipes PSL2 Chemical Composition
| Mass Fraction, based upon heat and product analyses | Carbon Equivalent % max | ||||||||||
| Steel grade | C | Si | Mn | P | S | V | Nb | Ti | Other | Ce | CE |
| L245 or Bm | 0.22 | 0.45 | 1.20 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| L290M or X42M | 0.22 | 0.45 | 1.30 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| L320M or X46M | 0.22 | 0.45 | 1.30 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| L360 or X52M | 0.22 | 0.45 | 1.40 | 0.025 | 0.015 | d | d | d | e,l | 0.43 | 0.25 |
| L390 or X56M | 0.22 | 0.45 | 1.40 | 0.025 | 0.015 | d | d | d | ,l | 0.43 | 0.25 |
| L415 or X60M | 0.12 | 0.45 | 1.60 | 0.025 | 0.015 | g | g | g | ,l | 0.43 | 0.25 |
| L450 or X65M | 0.12 | 0.45 | 1.60 | 0.025 | 0.015 | g | g | g | ,l | 0.43 | 0.25 |
| L485 or X70M | 0.12 | 0.45 | 1.60 | 0.025 | 0.015 | g | g | g | ,l | 0.43 | 0.25 |
API 5L X60 PSL1 Welded Pipes Comparative Specifications
The information here is summarized from ASTM Standards and API Specification 5L. Please see the specific standards for more information.
API Specification 5L x60 PSL 1 and PSL 2 Comparison information.
| Grade Range | A25 Through X70 | Gr B Through X80 | Table 1 |
| Size Range | 0.405 Through 80 | 4-2/1 Through 80 | Table 1 |
| Type Of Pipe Ends | Plain-End, Threaded-end, Bevelled-End, Special Coupling Pipe | Plain-End | Table 1 |
| Seam Welding | All Methods Continous Welding Limited to Grade A25 | All Methods Except Continous And Laser Welding | Table 1 |
| Electric Welds: Welder Frequency | No Minimum | 100 Khz Minimum | 5.1.3.3.2 |
| Heat Treatments of Electric Welds | Required For Grades > X42 | Required For All Grades (Gr B Through X80) | 5.1.3.3.1; J.3.3.2:6.2.7 |
| Chemistry: Max C For Seamless Pipe | 0.28% For Grades > Gr B | 0.24% | tables 2a, 2b |
| Chemistry: Max C For Welded Pipe | 0.26% For Grades > Gr B | 0.22% | tables 2a, 2b |
| Chemistry: Max P | 0.03% | 0.03% | Tables 2a, 2b |
| Chemistry: Max S | Only When Purchases Specifies Sr18 | 0.02% | Tables 2a, 2b |
| Carbon Equivalent | None | Maximum Required for Each Grade | 4.2:4.3:6.1.3: Sr15.1 |
| Yield Strength, Maximum | None | Maximum for Each Grade | tables 3a, 3b |
| UTS, Maximum | None Required | Maximum For Each Grade | Tables 3a, 3b |
| Fracture Toughness | Only When Purchaser Specifies Sr4 | Required For All Grades | 6.2.6; 9.3.5: 9.8.4; 9.10.7; |
| Non-destructive Inspection of Seamless Pipes | Permitted | sr4 Mandatory | table 14 9.7.2.6 |
| Repair By Welding of Pipe Body, Plate And Skelp | Permitted By Agreement | Prohibited | 5.3.2;9.7.6: B.1;b.2 |
| Certification | Certificates When Specified Per Sr15 | Prohibited | 4.3;9.7.4.4;9.7.6;b.1.2;b.4 |
| Traceability | Traceable Only Until All Tests are Passed Unless Sr15 Is Specified | Certificates (Sr15.1) Mandatory Traceable After Completion of Tests (Sr15.2) Mandatory |
12.1 5.6 |
| Country Name | Latest Price/ Recent Updated Price 2017-18 |
| API 5L X60 PSL1 Pipe Price in Indonesia | US $850 - 950 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Malaysia | US $850 - 990 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in United Arab Emirates | AED 3121.84 - 3489.11/ Metric Ton |
| API 5L X60 PSL1 Pipe Price in Singapore | US $850 - 995 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Iran | US $850 - 950 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in South Korea | US $850 - 1350 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Egypt | US $850 - 1150 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Saudi Arabia | US $850 - 950 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Kuwait | US $850 - 950 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in South Africa | US $850 - 1100 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Qatar | US $850 - 950 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Bahrain | BD 320-358 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Oman | US $850 - 950 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in India | INR 56988-63692/ Metric Ton |
| API 5L X60 PSL1 Pipe Price in Taiwan | US $850 - 950 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in Vietnam | US $850 - 1250 / Metric Ton |
| API 5L X60 PSL1 Pipe Price in USA | US $850 - 1050 / Metric Ton |
CHEMICAL REQUIREMENTS for API 5L x60 PSL1 steel Pipe
API 5L Specifications Covers Seamless and Welded pipe suitable for use in conveying gas, water, oil, and other liquefied media. The attached requirements cover our offering of API 5L 45th Ed, PSL 1Seamless and Welded; API 5L 45th Ed PSL 2 Seamless & Welded; and API 5L 45th Ed PSL2 Welded only.
TENSILE PROPERTIES for Seamless and Welded API 5L x60 PSL1 steel Pipe
tensile properties data for Seamless and Welded API 5L steel pipe and Stainless Steel API 5L 45th Ed PSL 1, PSL 2.
TESTING REQUIREMENTS for Seamless and Welded API 5L x60 PSL1 steel Pipe
Our API 5L Welded Pipes hydrostatic and mechanical testing information for all sizes and grades covered by the specification.
Permissible Variations for Seamless and Welded API 5L x60 psl1 steel Pipe
| Grade A, B, A25 | X42 through X80 | |
| NPS 2-1/2 and smaller --Seamless and Welded, % | +20 -- 12.5 | +15 -- 12.5 |
| NPS 3 --Seamless and Welded, % | +18 -- 12.5 | +15 -- 12.5 |
| NPS 4 through 18 --Seamless and Welded, % | +15 -- 12.5 | +15 -- 12.5 |
| NPS 20 and larger -- Welded, % | +17.5 -- 10.0 | +19.5 -- 8.0 |
| NPS 20 and larger -- Seamless, % | +15.0 -- 12.5 | +17.5 -- 10.0 |
Marking Requirements
Paint-stenciled or die-stamped manufacturer’s name or mark, Spec 5L, size, weight per foot, grade, process of manufacture, type of steel, length (NPS 4 and larger only). Test pressure when High Temperature than tabulated (NPS 2 and larger only).
Supplemental Annexes for API 5L x60 PSL1Seamless and Welded steel Pipe
API Specification 5L contains 15 Supplemental Annexes that address special conditions and/or additional requirements.
API 5L Line Pipes OF TOP APPROVED COMPANIES
 Sabic Saudi Arabia) |
 Shell |
 ALBA (Saudi Arabia) |
 QAFCO(Qatar) |
 Maaden(Saudi Arabia) |
 KNPC(Kuwait) |
 Kuwait Oil Company(Kuwait) |
 Qatar Petroleum(Qatar) |
 Petroleum Development Oman(Oman) |
 ADNOC(United Arab Emirates) |
 Orpic(Oman) |
 Takreer(Abu Dhabi) |
 YASREF(Abu Dhabi) |
 Petrobras(Brazil) |
 Petronas(Malaysia) |
 NIOC(Iran) |
 NPDC(Nigeria) |
 Egyptian General petroleum Corporation(Egypt) |
Supplying API 5L x60 PSL1 Pipes to Countries
We Export API 5L X60 PSL1 Welded Pipe to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen, Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East. etc
Savoy Piping Inc. is a well known worldwide exporter of API 5L X60 PSL1 Welded Pipe is committed to provide each and every customer with the highest standard of customer service. We deals in API 5L X60 PSL1 Welded Pipe in India and Overseas, offering a wide range of API 5L X60 PSL1 Welded Line Pipes
