ASTM A182 F44 Flanges / UNS S31254 Flanges / SMO 254 Flanges

ASTM A182 F44 Flanges, ASME SA182 F44 Flanges, ASTM A182 UNS S8904 Flange, A182 SMO 254 Flanges, Stainless Steel SMO 254 Flanges, UNS S31254 Stainless Steel Flanges, SS F44 Flanges, Manufacturer in India.

Savoy Piping Inc., is an ISO 9001:2015, PED/27/EC and OHSAS 18001:2007 Approved Manufacturer of ASTM A182 F44 Flanges in Specification in Types Like A182 F44 Weldneck Flange, A182 F44 Blind Flange, A182 F44 Socketweld Flange, A182 F44 Slip On Flange, A182 F44 Threaded Flange, A182 F44 Laped Joint Flange, A182 F44 Screw Flange, A182 F44 Plate Flange, 44 WNRF Flange, BLRF Flange, SWRF Flange, A182 F44 SORF Flange etc.

Manufacturer and Exporter of ASTM A182 F44 Flanges in Dimension accordance with ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092-1, DIN, etc. Certified with NACE, PWHT, HIC, SSC, Magnetic Particle Test, Dye Penereteration Test etc.


ASTM A182 F44 Flanges, ASTM A182 SMO 254, ASTM A182 F44 Weldneck Flange, F44 Blind Flange, ASTM A182 F44 Socketweld Flange, ASTM A182 F44 Slip On Flange, ASTM A182 F44 Threaded Flange, ASTM A182 F44 Laped Joint Flange, ASTM A182 F44 Screw Flange, ASTM A182 F44 Plate Flange, ASTM A182 F44 WNRF Flange, ASTM A182 FBLRF Flange, SWRF Flange, ASTM A182 F44 SORF Flanges

ASTM A182 F44 Flange - Content

Here's an introduction to ASTM A182 F44 flanges:

ASTM A182 F44 is a forging material specification for grade 44 stainless steel, used to produce bright forgings or forged and machined products for high temperature applications.

ASTM A182 F44 Flange is Material to F44 Super Austenitic Stainless Steel is described as a 6% Mo Flanges super austenitic stainless
steel. The steel combines moderate mechanical strength (typically over 300 MPa yield strength) and high ductility with excellent corrosion resistance in seawater and a variety of industrial environments. Typically the alloy has a PREn(Pitting Resistance Equivalent) of 42-44 which ensures that the resistance to pitting corrosion is high. In addition, the steel provides good resistance to crevice corrosion.

SMO 254 flanges are in ASTM A182 specification with sizes from ½ inch to 48 inch. There are different standards for sizing such as ASME, ANSI, DIN and other international standards. astm a182 f44 are manufactured in various production forms such as forged, bolted, threaded and flat flanges. There are also different functional types such as sliding flanges, ring flanges, hole flanges, Weld Neck Flange and blind flanges. Blind flanges also come in different varieties, such as the SMO 254 Spectacle blind flange. Each flange type has a purpose to fulfill in an application. The face type of the flange is also different.

Raised, flat and ring flanges are available from Pressure Vessel classes 150 to 2500. ASTM a182 f44 and other flanges are made from chromium, nickel and molybdenum alloys. This material contains 19 % chromium, 17% nickel, 6% molybdenum with carbon,and Carbon Steel manganese, silicon, copper, sulfur and sulfur. Different types of flanges such ASUNS s31254 have good corrosion resistance due to their composition. The Flange Standard are also stronger than conventional stainless steel flanges with a minimum tensile strength of 650 MPa, a minimum yield strength of 300 MPa and an elongation rate of 35%. UNS S31254 weld neck flange is preferred in welding applications. These clamps can hold the pipe and Weld Pipein place during welding. This material has a melting point of up to 1390 degrees Celsius, so it can be used in high-temperature and high-pressure applications such as power generation, heat exchangers, boilers and industrial applications. petrochemical industry.

Material Composition:

  • ASTM A182 F44 is a duplex stainless steel, which means it has a dual-phase microstructure consisting of both austenitic and ferritic phases.
  • The chemical composition of ASTM A182 F44 typically includes elements such as chromium, molybdenum, nickel, and nitrogen, which contribute to its corrosion resistance and mechanical properties.

Corrosion Resistance:

  • One of the key features of ASTM A182 F44 is its excellent corrosion resistance, particularly in aggressive environments such as chloride-containing media.
  • The duplex structure of F44 provides a balanced combination of strength and corrosion resistance, making it suitable for demanding applications.

High Temperature Service:

  • ASTM A182 F44 is designed for use in high-temperature and high-pressure applications, making it suitable for various industries where these conditions are common.

Applications:

  • F44 flanges find widespread use in industries such as chemical processing, petrochemical, oil and gas exploration and production, and offshore industries.
  • Common applications include pressure vessels, heat exchangers, pipelines, and other components subjected to corrosive and high-temperature environments.

Manufacturing Standards:

  • ASTM A182 F44 flanges are manufactured according to the standards outlined in ASTM A182, which specifies the requirements for forged or rolled alloy and stainless steel pipe flanges, forged fittings, and valves.

Types of Flanges:

  • F44 flanges can come in various types, including weld neck, slip-on, socket weld, blind, and lap joint flanges, among others, each serving specific purposes in piping systems.

Testing and Certification:

  • ASTM A182 F44 flanges undergo rigorous testing to ensure they meet the specified mechanical and chemical properties. Common tests include hydrostatic testing, tensile testing, and non-destructive testing.
  • Flanges meeting the requirements of ASTM A182 F44 are typically supplied with relevant documentation and certifications.

It's important to note that when specifying or using ASTM A182 F44 Flanges, and Alloy Steelit's crucial to follow the specific requirements outlined in the ASTM A182 standard to ensure proper material performance and reliability in the intended service conditions.

Savoy Piping Inc. are recognized as the prominent Manufacturer, Exporter and Supplier of a broad assortment of A182 F44 Flanges. The offered ASTM A182 F44 Flanges is designed with utmost precision in conformity with the international quality standards.

ASTM A182 F44 Flange Range

ASTM A182 F44 Flange Specification ASTM A182 / ASME SA182
ASTM A182 F44 Flange Manufacturing Process Hot Forging / Rolling / Machining
ASTM A182 F44 Flange Other Grades 202 / 304 / 304L / 304H / 309S / 310S / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc.
UNS No. - UNS S30400, UNS S30403, UNS S31008, UNS S31620, UNS S31603, UNS S31603, UNS S31635, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904
EN No. - 1.4301, 1.4307, 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539
ASTM A182 F44 Flange Outer Diameter 1/2" NB TO 64" NB
ASTM A182 F44 Flange Pressure Class Class 150#, Class 300#, Class 400#, Class 600#, Class 900#, Class 1500#, Class 2500# or As Per Custom Requirement
PN 6, PN 10, PN 16, PN 25 and PN 40 etc
ASTM A182 F44 Flange Schedule Sch 10s TO Sch XXS or As Per Custom Requirement
ASTM A182 F44 Flange Facing Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
ASTM A182 F44 Flange Dimension ASME B16.5, ASME B16.47 SERIES A, ASME B16.47 SERIES B, ASME B16.36, BS10, EN1092-1:2013, MSS SP44, ASA, API-605, ISO 7005, ISO 15590-3, DIN 2631--2638, DIN 2573-2576, DIN 2527, DIn 2641-2642, DIN 2565-2566, DIN2502, AWWA, AS2129 TABLE C, D, E, F, J etc..
ASTM A182 F44 Flange Types Welding Neck Flange, Slip On Flange, Socket Weld Flanges, Lap Joint Flange, Threaded Flange, Blind Flange, Orifice Flanges, Plate Flange, Long Welding Neck Flanges, Weldoflange, Nipoflange, Expander Flange, Reducing Flange, WNRF Flange, SORF Flange, SWRF Flange, Custom Flange as per Drawing etc.
ASTM A182 F44 Flange Other Testing NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, HIC, SSC, Sour Service etc.
ASTM A182 F904L Flange Value Added Services Rolling, Drill, Punch, CNC Machining, Sand Blasting, Shot Blasting, Heat Treatment, Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized
ASTM A182 F44 Flange Packaging Loose / Carrate / Wooden Pallet / Wooden Box / Plastic Cloth Wraps
ASTM A182 F44 Flange Shipment & Transportation By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes
ASTM A182 F44 Flange Material Test Certificate Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC

ASTM A182 F44 Flange Chemical Compostion and Properties

The chemical composition of grade ASTM A182 F44 Flange is outlined in the following table

Steel Grade C Si Mn P S Cr Ni Mo Cu N
F44 0.02 max 0.8 max 1.0 max 0.030 max 0.010 max 19.5-20.5 17.5-18.5 6.0-6.5 0.50-1.00 0.18-0.22
1.4547 0.02 max 0.7 max 1.0 max 0.030 max 0.010 max 19.5-20.5 17.50-18.50 6.0-7.0 0.50-1.00 0.18-0.25

ASTM A182 F44 Flange Mechanical and Physical Properties

ASTM A182 F44 Flange Physical Properties

Physical properties of ASTM A182 F44 grade Stainless Steel in the annealed condition

Hardness (HB) Tensile Strength (Mpa) Yield Strength (Mpa) Elongation (%) (Long.) Impact Value (J) (Long.)
260 max 650-850 300-340 35 min 100 min

ASTM A182 F44 Flange Price

ASTM A182 F44 Flange Manufacturer Name and Origin

ASTM A182 F44 Flange is in Ready Stock and Ready to Deliver. High Quality, Lower Cost But Best Service in Flanges

ASTM A182 F44 Flange Application

  • Oil and Gas Industries
  • Food Processing Industries
  • Equipments
  • Pipeline
  • Power Industries
  • Ship Building Industries
  • Paper Industries
  • Cement Industries
  • Chemical Industries

ASTM A182 F44 Flanges Available Offer and Discounts

Buy Now ASTM A182 F44 Flange at an Attactive Discounted Price, Order Above USD $ 25000 are Eligible of 2% Discount. We Offer Free Insurance and Best Shipping Rates. Our Prices are Always More Competitive and without any compromise in Quality of the Material.

ASTM A182 F44 Flanges Types

  • ASTM A182 F44 Welding Neck Flange
  • ASTM A182 F44 Slip On Flange
  • ASTM A182 F44 Socket Weld Flange
  • ASTM A182 F44 Lap Joint Flange
  • ASTM A182 F44 Threaded Flange
  • ASTM A182 F44 Blind Flange
  • ASTM A182 F44 Orifice Flanges
  • ASTM A182 F44 Long Welding Neck Flanges
  • ASTM A182 F44 Weldoflange
  • ASTM A182 F44 Nipoflange
  • ASTM A182 F44 Expander Flange
  • ASTM A182 F44 Reducing Flange
  • ASTM A182 F44 WNRF Flange
  • ASTM A182 F44 SORF Flange
  • ASTM A182 F44 SWRF Flange
  • ASTM A182 F44 BLRF Flange

ASTM A182 F44 Packing Shipment

ASTM A182 F44 Flange is Covered with Plastic Cloth and Packed in Wooden Box, Wooden Pallet and Wooden Fumigated Carrate. Our Packaging is Fully Waterproof and Safe for Transport with Proper Strips on Wooden Box, having Lifting Point.

ASTM A182 F44 Flange Exported Countries

We Export ASTM A182 F44 Flanges and other Componentsto Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen , Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States Of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East.etc

ASTM A182 F44 Flanges Supplying in States and Cities

We Supply ASTM A182 F44 Flanges Andhra Pradesh, Arunachal Pradesh, Assam, Bihar, Chhattisgarh, Goa, Gujarat, Haryana, Himachal Pradesh, Jammu and Kashmir, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Maharashtra, Manipur, Meghalaya, Mizoram, Nagaland, Odisha, Punjab, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Uttar Pradesh, Uttarakhand, West Bengal, Mumbai, Navi Mumbai, Pune, Nashik, Nagpur, Solapur, Kolhapur, Ambernath, Ahmednagar, Latur, Ahmadabad, Surat, Rajkot, Vadodara, Panaji, Madgaon, Chennai, Kolkata, Hyderabad, Bengaluru, Delhi, New Delhi, Ludhiana, Chandigarh, Raipur, Bhopal, Jamshedpur, Vishakhapatnam, Cochin, Ghaziabad, Noida, Gurugram, Bhillai, Durgapur, Vijaywada, Kanpur etc.

Savoy Piping Inc., is a well known worldwide Exporter of ASTM A182 F44 Flanges, Savoy Piping Inc., is committed to provide each and every customer with the highest standard of customer service. We deals in ASTM A182 F44 Flanges in India and Overseas, offering a wide range of ASTM A182 F44 Flanges
