ASTM A182 F310s Flanges, ASME SA182 F310s Flanges, ASTM A182 UNS S31008Flange, Stainless Steel 310s Flanges, 310s Stainless Steel Flanges, SS 310s Flanges, Manufacturer in India.
Savoy Piping Inc., is an ISO 9001:2015, PED/27/EC and OHSAS 18001:2007 Approved Manufacturer of ASTM A182 F310s Flanges in Specification in Types Like A182 F310s Weldneck Flange, A182 F310s Blind Flange, A182 F310s Socketweld Flange, A182 F310s Slip On Flange, A182 F310s Threaded Flange, A182 F310s Laped Joint Flange, A182 F310s Screw Flange, A182 F310s Plate Flange, 310s WNRF Flange, BLRF Flange, SWRF Flange, A182 F310s SORF Flange etc.
Manufacturer and Exporter of ASTM A182 F310s Flanges in Dimension accordance with ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092-1, DIN, etc. Certified with NACE, PWHT, HIC, SSC, Magnetic Particle Test, Dye Penereteration Test etc.
ASTM A182 F310s Flange - Content
- What is ASTM A182 F310s Flanges
- ASTM A182 F310s Flanges Available Range
- ASTM A182 F310s Flanges Chemical Composition
- ASTM A182 F310s Flanges Mechanical and Physical Properties
- ASTM A182 F310s Flanges Price
- ASTM A182 F310s Flanges Manufacturer, Mill Name and Origin
- ASTM A182 F310s Flanges Application and Usage
- ASTM A182 F310s Flanges Available Offer and Discount Best Price
- ASTM A182 F310s Flanges Types
- ASTM A182 F310s Flanges Packing and Shipment
- ASTM A182 F310s Flanges Export Countries
- ASTM A182 F310s Flanges Supplying States and Cities
Here is a brief Introduction to ASTM A182 F310S flanges:
ASTM A182 is the Standard Specification for Forged Stainless Steel Pipe Flanges and Stainless Steel Forged Fittings. ASTM 182 is use in pressure systems, Included are flanges, fittings and similar parts to specified dimensions or to dimensional standards, such as the ASME specifications. ASTM A182 F310s Flange combining excellent high temperature properties with good ductility and weldability, is designed for high temperature service. It resists oxidation in continuous service at temperatures up to 1150°C provided reducing sulphur gases are not present. It is also used for intermittent service at temperatures up to 1040°C.
A182 F310S Flanges (UNS S31008) is used when the application environment involves moist corrodents in a temperature range lower than that which is normally considered "high temperature" service. The lower carbon content and Carbon Steel of 310S does reduce its high temperature strength compared to 310.ASTM A182 F310s Flanges is readily available for applications in the industrial, architectural, and transportation fields.
ASTM A182 F310S is a specification standard developed by ASTM International for forged or rolled alloy and stainless steel pipe flanges, Steel Pipe Fittings , forged fittings, and valves, intended for use in high-temperature and corrosive service environments. Specifically, ASTM A182 F310S focuses on flanges made from a particular type of stainless steel alloy known as Grade F310S.
Material Composition:
- ASTM A182 F310S is a modification of the widely used Grade 310 stainless steel.
- The "S" in F310S indicates that the material has a lower carbon content compared to standard Grade 310, making it suitable for high-temperature service without the risk of sensitization.
Chemical Composition:
The chemical composition of ASTM A182 F310S includes elements such as chromium, nickel, and manganese, which contribute to its high-temperature resistance and corrosion resistance properties.
High-Temperature Applications:
F310S flanges are designed for service in high-temperature environments, such as those encountered in heat treatment and thermal processing industries.
Corrosion Resistance:
The alloy's composition provides excellent corrosion resistance, making it suitable for applications where exposure to corrosive substances is a concern.
Forging and Heat Treatment:
- langes made to this specification are typically produced by forging or rolling processes, ensuring a high level of strength and integrity.
- Heat treatment is often employed to achieve the desired mechanical properties.
Flange Types and Classes:
- ASTM A182 F310S flanges come in various types, including weld neck, slip-on, socket weld, blind, and threaded flanges, among others.
- The specification also includes different pressure classes (e.g., 150, 300, 600, etc.), allowing for a range of applications.
Compliance with Standards:
Flanges manufactured according to ASTM A182 F310S are expected to meet certain standards and specifications set by ASTM International, ensuring quality and performance.
Applications:
Common applications for ASTM A182 F310S flanges include high-temperature piping systems in industries such as petrochemical, chemical, power generation, and refining.
It's essential to consult the specific requirements of the project or application and adhere to the guidelines outlined in the ASTM A182 F310S standard to ensure proper material selection and performance in the intended service conditions.
Savoy Piping Inc are recognized as the prominent Manufacturer, Exporter and Supplier of a broad assortment of A182 F310s Flanges. The offered ASTM A182 F310s Flanges is designed with utmost precision in conformity with the international quality standards.
ASTM A182 F310s Flange Range
| ASTM A182 F310s Flange Specification | ASTM A182 / ASME SA182 |
| ASTM A182 F310s Flange Manufacturing Process | Hot Forging / Rolling / Machining |
| ASTM A182 F310s Flange Other Grades | 202 / 304 / 304L / 304H / 309S / 310S / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc. UNS No. - UNS S30400, UNS S30403, UNS S31008, UNS S31620, UNS S31603, UNS S31603, UNS S31635, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904 EN No. - 1.4301, 1.4307, 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539 |
| ASTM A182 F310s Flange Outer Diameter | 1/2" NB TO 64" NB |
| ASTM A182 F310s Flange Pressure Class | Class 150#, Class 300#, Class 400#, Class 600#, Class 900#, Class 1500#, Class 2500# or As Per Custom Requirement PN 6, PN 10, PN 16, PN 25 and PN 40 etc |
| ASTM A182 F310s Flange Schedule | Sch 10s TO Sch XXS or As Per Custom Requirement |
| ASTM A182 F310s Flange Facing | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| ASTM A182 F310s Flange Dimension | ASME B16.5, ASME B16.47 SERIES A, ASME B16.47 SERIES B, ASME B16.36, BS10, EN1092-1:2013, MSS SP44, ASA, API-605, ISO 7005, ISO 15590-3, DIN 2631--2638, DIN 2573-2576, DIN 2527, DIn 2641-2642, DIN 2565-2566, DIN2502, AWWA, AS2129 TABLE C, D, E, F, J etc.. |
| ASTM A182 F310s Flange Types | Welding Neck Flange, Slip On Flange, Socket Weld Flange, Weld Neck Flange , Lap Joint Flange, Threaded Flange, Blind Flange, Orifice Flanges, Plate Flange, Long Welding Neck Flanges, Weldoflange, Nipoflange, Expander Flange, Reducing Flange, WNRF Flange, SORF Flange, SWRF Flange,Copper Nickel , Custom Flange as per Drawing etc. |
| ASTM A182 F310s Flange Other Testing | NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, HIC, SSC, Sour Service etc. |
| ASTM A182 F310s Flange Value Added Services | Rolling, Drill, Punch, CNC Machining, Sand Blasting, Shot Blasting, Heat Treatment, Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized |
| ASTM A182 F310s Flange Packaging | Loose / Carrate / Wooden Pallet / Wooden Box / Plastic Cloth Wraps |
| ASTM A182 F310s Flange Shipment & Transportation | By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / Pressure Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| ASTM A182 F310s Flange Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC |
ASTM A182 F310s Flange Chemical Compostion and Properties
The chemical composition of grade ASTM A182 F310s Flange is outlined in the following table
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 310 | min. max. |
- 0.25 |
- 2.00 |
- 1.50 |
- 0.045 |
- 0.030 |
24.0 26.0 |
- | 19.0 22.0 |
- |
| 310S | min. max. |
- 0.08 |
- 2.00 |
- 1.50 |
- 0.045 |
- 0.030 |
24.0 26.0 |
- | 19.0 22.0 |
- |
ASTM A182 F310s Flange Mechanical and Physical Properties
The mechanical properties of grade ASTM A182 F310s Flange are displayed in the following table.
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max |
||||
| 310 | 515 | 205 | 40 | 95 | 217 |
| 310S | 515 | 205 | 40 | 95 | 217 |
ASTM A182 F310s Flange Physical Properties
Physical properties of ASTM A182 F310s grade Stainless Steel in the annealed condition
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion(μm/m/°C) | Thermal Conductivity(W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 310 / 310S | 7750 | 200 | 15.9 | 16.2 | 17.0 | 14.2 | 18.7 | 500 | 720 |
ASTM A182 F310s Flange Price
- USD $ 5500 Per Metric Ton - ASTM A182 F310s Flange
- USD $ 5500 Per Metric Ton - Stainless Steel ASTM A182 F310s Flange
- USD $ 5600 Per Metric Ton - SS ASTM A182 F310s Flange
- USD $ 5400 Per Metric Ton - ASTM A182 F310s Stainless Steel Flange
- USD $ 5500 Per Metric Ton - ASTM A182 F310s Weldneck Flange
- USD $ 5520 Per Metric Ton - ASTM A182 F310s Socketweld Flange
- USD $ 5450 Per Metric Ton - ASTM A182 F310s Blind Flange
- USD $ 7690 Per Metric Ton - ASTM A182 F310s Slip On Flange
- USD $ 5200 Per Metric Ton - ASTM A182 F310s Lap Joint Flange
- USD $ 6420 Per Metric Ton - ASTM A182 F310s Threaded Flange
- USD $ 5650 Per Metric Ton - ASTM A182 F310s Reducing Flange
ASTM A182 F310s Flange Manufacturer Name and Origin
- ASTM A182 F310s Flange - Savoy Piping Inc., Make, Origin - India
- ASTM A182 F310s Flange - Ulma, Origin - Spain
- ASTM A182 F310s Flange - Matalfar, Origin - Italy
- ASTM A182 F310s Flange - Kofco, Origin - South Korea
- ASTM A182 F310s Flange - Melesi, Origin - Italy
- ASTM A182 F310s Flange - Viraj, Origin -India
- ASTM A182 F310s Flange - Galpetri, Origin - Italy
- ASTM A182 F310s Flange - Korea Flages, Origin - South Korea
- ASTM A182 F310s Flange - N.K Forge, Origin - Japan
- ASTM A182 F310s Flange - Ring Mill, Origin - Italy
- ASTM A182 F310s Flange - WMASS, Origin - India
- ASTM A182 F310s Flange - Korea Metal, Origin - South Korea
- ASTM A182 F310s Flange - Cladtek, Origin - South Korea
- ASTM A182 F310s Flange - CHW Forge Origin - India
ASTM A182 F310s Flange is in Ready Stock and Ready to Deliver. High Quality, Lower Cost But Best Service in Flanges
ASTM A182 F310s Flange Application
- Oil and Gas Industries
- Food Processing Industries
- Equipments
- Pipeline
- Power Industries
- Ship Building Industries
- Paper Industries
- Cement Industries
- Chemical Industries
ASTM A182 F310s Flanges Available Offer and Discounts
Buy Now ASTM A182 F310s Flange and Componentsat an Attactive Discounted Price, Order Above USD $ 25000 are Eligible of 2% Discount. We Offer Free Insurance and Best Shipping Rates. Our Prices are Always More Competitive and without any compromise in Quality of the Material.
ASTM A182 F310s Flanges Types
- ASTM A182 F310s Welding Neck Flange
- ASTM A182 F310s Slip On Flange
- ASTM A182 F310s Socket Weld Flange
- ASTM A182 F310s Lap Joint Flange
- ASTM A182 F310s Threaded Flange
- ASTM A182 F310s Blind Flange
- ASTM A182 F310s Orifice Flanges
- ASTM A182 F310s Long Welding Neck Flanges
- ASTM A182 F310s Weldoflange
- ASTM A182 F310s Nipoflange
- ASTM A182 F310s Expander Flange
- ASTM A182 F310s Reducing Flange
- ASTM A182 F310s WNRF Flange
- ASTM A182 F310s SORF Flange
- ASTM A182 F310s SWRF Flange
- ASTM A182 F310s BLRF Flange
ASTM A182 F310s Packing Shipment
ASTM A182 F310s Flange is Covered with Plastic Cloth and Packed in Wooden Box, Wooden Pallet and Wooden Fumigated Carrate. Our Packaging is Fully Waterproof and Safe for Transport with Proper Strips on Wooden Box, having Lifting Point.
ASTM A182 F310s Flange Exported Countries
We Export ASTM A182 F310s Flanges to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen , Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States Of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East.etc
ASTM A182 F310s Flanges Supplying in States and Cities
We Supply ASTM A182 F310s Flanges Andhra Pradesh, Arunachal Pradesh, Assam, Bihar, Chhattisgarh, Goa, Gujarat, Haryana, Himachal Pradesh, Jammu and Kashmir, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Maharashtra, Manipur, Meghalaya, Mizoram, Nagaland, Odisha, Punjab, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Uttar Pradesh, Uttarakhand, West Bengal, Mumbai, Navi Mumbai, Pune, Nashik, Nagpur, Solapur, Kolhapur, Ambernath, Ahmednagar, Latur, Ahmadabad, Surat, Rajkot, Vadodara, Panaji, Madgaon, Chennai, Kolkata, Hyderabad, Bengaluru, Delhi, New Delhi, Ludhiana, Chandigarh, Raipur, Bhopal, Jamshedpur, Vishakhapatnam, Cochin, Ghaziabad, Noida, Gurugram, Bhillai, Durgapur, Vijaywada, Kanpur etc.
Savoy Piping Inc., is a well known worldwide Exporter of ASTM A182 F310s Flanges, Savoy Piping Inc., is committed to provide each and every customer with the highest standard of customer service. We deals in ASTM A182 F310s Flanges in India and Overseas, offering a wide range of ASTM A182 F310s Flanges
