ASTM A182 F9 is a forging material specification for grade 9 stainless steel, used to produce bright forgings or forged and machined products for high temperature applications.
F9 alloy steel flanges are thinner than other flanges. As a result, ASTM A182 F9 blind flanges tend to fit well in compact workspaces. In addition, the a182 f9 material contains a certain amount of chromium and molybdenum, both of which help maintain longevity, thus providing a long service life. In addition, the addition of chromium and molybdenum in grade a182 f9 improves the corrosion resistance of the flanges
Due to its slim dimensions and economical price combined with a long service life, the A182 F9 Flange is considered an economical choice. Besides these properties, the astm a182 f9 is reusable and non-corrosive The A182 GR F9 Alloy Steel Flange generally confirm to the ASTM Grade A182. The standard for the ASTM Grade A182 is a specification meant for rolled or forged Alloy flanges which are to be used for high pressured applications and systems. Besides having good resistance to corrosion, adding Chromium and Molybdenum in the alloy also enhances its ductility A182 gr f9 alloy steel flange generally conforms to ASTM A182. Standard for grade ASTM A182 is the specification for forged or rolled alloy flanges used for high pressure applications and systems. Besides good corrosion resistance, the addition of chromium and molybdenum in the alloy also improves its ductility The mechanical properties of ASTM A182 F9 Flange include high tensile strength, good corrosion resistance, improved hardness as well as toughness. For example, the tensile strength is 380 Mpa, while its yield strength is 0.2% Offset585 Mpa. The elongation of ASTM A182 GR f9 is 20%.
These characteristics are attributed to the presence of alloying elements such as Chromium and Molybdenum The astm A182 Grade F9 is a very versatile device. Hence, it can be applied in many industries such as pharmaceutical equipment, pharmaceuticals, chemical equipment, sea water equipment, heat exchangers, condensers, pulp and paper industry, power generation, off-shore oil drilling companies, gas processing, petrochemicals and specialty chemicals. Thealloy steel f9 flanges manufacturers produce three types of Flange Face i.e., Raised Face (RF), Ring Type Joint (RTJ) and Flate Face (FF).
F9 Alloy Steel Lapped joint Flanges, Alloy Steel ASTM A182 F9 Threaded Flanges, Alloy Steel 9Cr-1Mo Socket Weld Flanges, ANSI B16.5, ANSI B16.47, B16.48, BS4504, BS 10, EN-1092 Alloy Steel F9 Forged Flanges, SA182M Alloy Steel F9 Pipe Flange, ASTM A182 F9 Weld Neck Flange Manufacturer Of A182 F9 Chrome Moly Plate Flange
ASTM A182 F9 alloy steel flange is a flange made from ASTM A182 F9 alloy steel grade. These flanges connect pipes or other equipment in high pressure and high temperature environments. ASTM A182 F9 is known for its high tensile strength, toughness and flexibility. Flanges come in a variety of shapes and sizes to suit different piping systems.
ASTM A182 F9 Alloy Steel Flanges have a wide variety of applications in petrochemical, chemical, power generation, oil and gas, and more. They are commonly used in piping systems for high temperature and high pressure applications including boilers, heat exchangers, pressure vessels and piping.
ASTM A182 F9 Alloy Steel Flanges offer a number of advantages including excellent corrosion resistance, high temperature resistance, and durability. They are very tough making them suitable for harsh environments and industries. They have high tensile strength and are easy to install and maintain. These flanges are also cost effective and offer a long life making them popular in many industries.
ASTM A182 F9 flanges are made from a specific type of Alloy Steel known as chromium-molybdenum steel. The alloy composition typically includes chromium, molybdenum, carbon, manganese, silicon, phosphorus, sulfur, and other elements. The inclusion of chromium and molybdenum enhances the flange's corrosion resistance and high-temperature strength.
These flanges are designed for applications that involve elevated temperatures, making them suitable for use in industries such as petrochemical, chemical, power generation, and refining, where high-temperature and high-pressure conditions are common.
ASTM A182 F9 flanges are manufactured using either forging or rolling processes. These methods impart strength and desirable mechanical properties to the flanges, ensuring they meet the specified performance requirements.
The ASTM A182 F9 specification covers various types of flanges, including weld neck,Stainless Steel ,slip-on, blind, socket weld, lap joint, and threaded flanges. Each type serves specific purposes and is designed for different applications and installation methods.
ASTM A182 F9 flanges undergo heat treatment processes to achieve the required mechanical properties. Heat treatment helps enhance the material's strength, hardness, and other mechanical characteristics, ensuring it can withstand the demanding conditions for which it is intended.
ASTM A182 F9 flanges must meet the requirements outlined in the ASTM A182 standard. This ensures uniformity in product quality, performance, and safety. Manufacturers and users can rely on the standard to guide the production and selection of these flanges.
Manufacturers of ASTM A182 F9 flanges typically provide certifications and conduct various tests to ensure the products meet the required standards. Common tests include chemical analysis, mechanical testing, hardness testing, and non-destructive testing.
ASTM A182 F9 flanges are essential components in high-temperature and high-pressure applications, known for their strength, durability, and resistance to corrosion. Users should adhere to the specified ASTM standards and consider the specific requirements of their applications when selecting and installing these flanges.
Savoy Piping Inc. are recognized as the prominent Manufacturer, Exporter and Supplier of a broad assortment of ASTM A182 F5 Flange, ASTM A182 F9 Flanges, ASTM A182 F11 Flange, ASTM A182 F22 Flange, ASTM A182 F91 Flange etc.
ASTM A182 F9 Flange Specification | ASTM A182 / ASME SA182 Class 1, Class 2, Class 3 |
ASTM A182 F9 Flange Manufacturing Process | Hot Forging / Rolling / Machining |
ASTM A182 F9 Flange Other Grades | ASTM A182 F5 Flange, ASTM A182 F9 Flanges, ASTM A182 F11 Flange, ASTM A182 F22 Flange, ASTM A182 F9, ASME SA182 F5 Flange, ASME SA182 F9 Flanges, ASME SA182 F11 Flange, ASME SA182 F22 Flange, ASME SA182 F91 Flange, A182 UNS K41545 Flange, A182 UNS K9094 Flange, A182 UNS K11572 Flange, A182 UNS K21590 Flange, A182 K91560 Flange |
ASTM A182 F9 Flange Outer Diameter | 1/2" NB TO 64" NB |
ASTM A182 F9 Flange Pressure Class | Class 150#, Class 300#, Class 400#, Class 600#, Class 900#, Class 1500#, Class 2500# or As Per Custom Requirement PN 6, PN 10, PN 16, PN 25 and PN 40 etc |
ASTM A182 F9 Flange Schedule | Sch 10s TO Sch XXS or As Per Custom Requirement |
ASTM A182 F9 Flange Facing | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
ASTM A182 F9 Flange Dimension | ASME B16.5, ASME B16.47 SERIES A, ASME B16.47 SERIES B, ASME B16.36, BS10, EN1092-1:2013, MSS SP44, ASA, API-605, ISO 7005, ISO 15590-3, DIN 2631--2638, DIN 2573-2576, DIN 2527, DIn 2641-2642, DIN 2565-2566, DIN2502, AWWA, AS2129 TABLE C, D, E, F, J etc.. |
ASTM A182 F9 Flange Types | Welding Neck Flange, Slip On Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Blind Flange, Orifice Flanges, Plate Flange, Long Welding Neck Flanges, Weldoflange, Nipoflange, Expander Flange, Reducing Flange, WNRF Flange, SORF Flange, SWRF Flange, Custom Flange as per Drawing etc. |
ASTM A182 F9 Flange Other Testing | NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, HIC, SSC, Sour Service etc. |
ASTM A182 F9 Flange Value Added Services | Rolling, Drill, Punch, CNC Machining, Sand Blasting, Shot Blasting, Heat Treatment, Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized |
ASTM A182 F9 Flange Packaging | Loose / Carrate / Wooden Pallet / Wooden Box / Plastic Cloth Wraps |
ASTM A182 F9 Flange Shipment & Transportation | By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
ASTM A182 F9 Flange Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC |
Material Group | Common Name | Type | UNS | Forging Spec. | Casting Spec. Equivalent | DIN | DIN W. No | Application |
---|---|---|---|---|---|---|---|---|
Low Alloy Steel | Moly Steel | C-1/2Mo | K12822 | A182-F1 cl2 | A217-WC1 | 15M03 | 1.5415 | Up to 470ºC* (875ºF) |
Alloy Steel Chrome Moly | 1.1/4Cr-1/2Mo | K11572 | A182-F11 cl2 | A217-WC6 | 13CRM044 | 1.7335 | Up to 593ºC (1100ºF) | |
2.1/4Cr-1Mo | K21590 | A182-F22 cl3 | A217-WC9 | 10CRM0910 | 1.7380 | Up to 593ºC (1100ºF), HP steam | ||
5Cr-1/2Mo | K41545 | A182-F5/F5a | A217-C5 | 12CRMO195 | 1.7362 | High temp refinery service | ||
9Cr-1Mo | K90941 | A182-F9 | A217-C12 | X 12 CrMo 9 1 | 1.7386 | High temp erosive refinery service | ||
9Cr-1Mo-V | A182-F91 | A217-C12A | X 10 CrMoVNb 9 1 | 1.4903 | High pressure steam |
The chemical composition of grade ASTM A182 F9 Flange is outlined in the following table
Grade | UNS# | Composition |
ASTM A182 F5 | K41545 | C .15 max, Mn .30 -.60, Cr 4.0 - 6.0, Mo .44 - .65 |
ASTM A182 F9 | K90941 | C .15 max, Mn .30 -.60, Cr 8.0 - 10.0, Mo .90 - 1.10 |
ASTM A182 F11 | K11572 | C .10 - .20, Mn .30 -.80, Cr 1.0 - 1.5, Mo .44 - .65 |
ASTM A182 F22 | K21590 | C .05 - .15, Mn .30 -.60, Cr 2.0 - 2.5, Mo .87 - 1.13, |
ASTM A182 F91 | K91560 | C .08 - .12, Mn .30 -.60, Cr 8.0 - 9.5, Mo .85 - 1.05, Cb .06 - .10, N .03 - .07, Al .04 max, V .18 - .25 |
(Max working pressure of Alloy Steel flanges ASTM A182 - by Class, in bar).
TEMP. C | 150# | 300# | 400# | 600# | 900# | 1500# | 2500# |
---|---|---|---|---|---|---|---|
-29 to 38 | 15.9 | 41.4 | 55.2 | 82.7 | 124.1 | 206.8 | 344.7 |
50 | 15.3 | 40 | 53.4 | 80 | 120.1 | 200.1 | 333.5 |
100 | 13.3 | 34.8 | 46.4 | 69.6 | 104.4 | 173.9 | 289.9 |
150 | 12 | 31.4 | 41.9 | 62.8 | 94.2 | 157 | 261.6 |
200 | 11.2 | 29.2 | 38.9 | 58.3 | 87.5 | 145.8 | 243 |
250 | 10.5 | 27.5 | 36.6 | 54.9 | 82.4 | 137.3 | 228.9 |
300 | 10 | 26.1 | 34.8 | 52.1 | 78.2 | 130.3 | 217.2 |
325 | 9.3 | 25.5 | 34 | 51 | 76.4 | 127.4 | 212.3 |
350 | 8.4 | 25.1 | 33.4 | 50.1 | 75.2 | 125.4 | 208.9 |
375 | 7.4 | 24.8 | 33 | 49.5 | 74.3 | 123.8 | 206.3 |
400 | 6.5 | 24.3 | 32.4 | 48.6 | 72.9 | 121.5 | 202.5 |
425 | 5.5 | 23.9 | 31.8 | 47.7 | 71.6 | 119.3 | 198.8 |
450 | 4.6 | 23.4 | 31.2 | 46.8 | 70.2 | 117.1 | 195.1 |
