ISO 15590-3 L415 Flanges, ISO 15590-3 L415 Carbon Steel Flanges, ISO 15590-3:2004 L415 Flanges, ISO 15590-3 L415 High Yield Pipe Flanges, ISO 15590-3 L415 API Pipe Flanges, ISO 15590-3 GRADE 415 Flanges, ISO 3183 L415 Pipe Flanges Manufacturer in India.
Savoy Piping Inc., is an ISO 9001:2015, PED/27/EC and OHSAS 18001:2007 Approved Manufacturer of ISO 15590-3 Flanges in Specification Grade L415 and Types Like ISO 15590-3 L415 Weldneck Flange, ISO 15590-3 L415 Blind Flange, ISO 15590-3 L415 Socketweld Flange, ISO 15590-3 L415 Slip On Flange, ISO 15590-3 L415 Threaded Flange, ISO 15590-3 L415 Laped Joint Flange, ISO 15590 L415 Screw Flange, ISO 15590-3 L415 Plate Flange, ISO 15590-3 L415 WNRF Flange, ISO 15590-3 L415 BLRF Flange, ISO 15590-3 L415 SWRF Flange, ISO 15590-3 L415 SORF Flange etc.
Manufacturer and Exporter of ISO 15590-3 L415 Flanges in Dimension accordance with ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092-1, DIN, etc. Certified with NACE, PWHT, HIC, SSC, Magnetic Particle Test, Dye Penereteration Test etc.
ISO 15590-3 L415 Flanges Carbon Steel - Content
- What is ISO 15590-3 L415 Flanges
- ISO 15590-3 L415 Flanges Available Range
- ISO 15590-3 L415 Flanges Chemical Composition
- ISO 15590-3 L415 Flanges Mechanical and Physical Properties
- ISO 15590-3 L415 Flanges Price
- ISO 15590-3 L415 Flanges Manufacturer, Mill Name and Origin
- ISO 15590-3 L415 Flanges Application and Usage
- ISO 15590-3 L415 Flanges Available Offer and Discount Best Price
- ISO 15590-3 L415 Flanges Types
- ISO 15590-3 L415 Flanges Packing and Shipment
- ISO 15590-3 L415 Flanges Export Countries
- ISO 15590-3 L415 Flanges Supplying States and Cities
ISO 15590-3 L290 Flanges Definition
ISO 15590-3 L415 Flanges is a method of connecting pipes, valves, pumps and other equipment to form a piping system. It also provides easy access for cleaning, inspection or modification. Flanges are usually welded or screwed. Flanged joints are made by bolting together two flanges with a gasket between them to provide a seal.
ISO 15590-3 L415 Flanges Petroleum and natural gas industries Induction bends, fittings and flanges for pipeline transportation systems b Part 3: Flanges)
ISO 15590-3 L415 Flanges This part of ISO 15590 applies to weldneck and blind flanges (full face, raised face, and RTJ groove) as well as anchor, swivel-ring flanges and orifice flanges.
This part of ISO 15590 specifies the technical requirements for carbon steel and low-alloy steel forged flanges for use in pipeline transportation systems for the petroleum and natural gas industries as defined in ISO 13623.
This part of ISO 15590 designates those categories of flanges that meet the industry's need to match ISO 3183 pipe. These flanges are for normal and low-temperature service and include supplementary requirements where required for sour service.
ISO 15590-3 L415 Flanges is readily available for applications in the Industrial and Transportation fields.
Savoy Piping Inc., are recognized as the prominent Manufacturer, Exporter and Supplier of a broad assortment of ISO 15590-3 L245 Flanges, ISO 15590-3 L290 Flanges, ISO 15590-3 L360 Flanges, ISO 15590-3 L415 Flanges, ISO 15590-3 L450 Flanges, ISO 15590-3 L485 Flanges. The offered ISO 15590-3 L360 Flanges is designed with utmost precision in conformity with the international quality standards.
ISO 15590-3 L415 Flanges Range
| ISO 15590-3 L415 Flanges Specification | ISO 15590-3:2004 |
| ISO 15590-3 L415 Flanges Manufacturing Process | Hot Forging / Rolling / Machining |
| ISO 15590-3 L415 Flanges Other Grades | ISO 15590-3 L245 / ISO 15590-3 L290 / ISO 15590-3 L360 / ISO 15590-3 L415 / ISO 15590-3 L450 / ISO 15590-3 L485 |
| ISO 15590-3 L415 Flanges Outer Diameter | 1/2" NB TO 64" NB |
| ISO 15590-3 L415 Flanges Pressure Class | Class 150#, Class 300#, Class 400#, Class 600#, Class 900#, Class 1500#, Class 2500# or As Per Custom Requirement PN 6, PN 10, PN 16, PN 25 and PN 40 etc |
| ISO 15590-3 L415 Flanges Schedule | Sch 10s TO Sch XXS or As Per Custom Requirement |
| ISO 15590-3 L415 Flanges Facing | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| ISO 15590-3 L415 Flanges Dimension | ASME B16.5, ASME B16.47 SERIES A, ASME B16.47 SERIES B, ASME B16.36, BS10, EN1092-1:2013, MSS SP44, ASA, API-605, ISO 7005, ISO 15590-3, DIN 2631--2638, DIN 2573-2576, DIN 2527, DIn 2641-2642, DIN 2565-2566, DIN2502, AWWA, AS2129 TABLE C, D, E, F, J etc.. |
| ISO 15590-3 L415 Flanges Types | Welding Neck Flange, Slip On Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Blind Flange, Orifice Flanges, Plate Flange, Long Welding Neck Flanges, Weldoflange, Nipoflange, Expander Flange, Reducing Flange, WNRF Flange, SORF Flange, SWRF Flange, Custom Flange as per Drawing etc. |
| ISO 15590-3 L415 Flanges Other Testing | NACE MR0175, Ultrasounic Test, Charpy Impact Test, Macro, Grain Size, Hardness, HIC, SSC, Sour Service, A for annealed, N for normalized, NT for Normalized and Tempered, or QT for Quenched and Tempered, Carbon Equivalent etc. |
| ISO 15590-3 L415 Flanges Value Added Services | Rolling, Drill, Punch, CNC Machining, Sand Blasting, Shot Blasting, Heat Treatment, Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized |
| ISO 15590-3 L415 Flanges Packaging | Loose / Carrate / Wooden Pallet / Wooden Box / Plastic Cloth Wraps |
| ISO 15590-3 L415 Flanges Shipment & Transportation | By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| ISO 15590-3 L415 Flanges Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved etc. |
ISO 15590-3 L415 Flanges Chemical Compostion and Properties
The chemical composition of grade ISO 15590-3 L415 Flanges is outlined in the following table
| Concentration in Alloys % mass fraction |
||||||
| Element | Non-sour service (designation N and L) |
Sour service (designation NS and LS) |
||||
| C | 0,20 | 0,18 | ||||
| Mn | 1,60 | 1,30 | ||||
| Si | 0,40 | 0,40 | ||||
| P | 0,025 | 0,025 | ||||
| S | 0,010 | 0,003 | ||||
| V | 0,10 | 0,10 | ||||
| Nb | 0,05 | 0,05 | ||||
| Ti | 0,04 | 0,04 | ||||
| Cr | 0,25 | 0,25 | ||||
| Mo | 0,10 | 0,10 | ||||
| Ni | 0,50 | 0,50 | ||||
| Cu | 0,35 | 0,35 | ||||
| Al | 0,06 | 0,05 | ||||
| N | 0,010 to 0,030 | 0,012 | ||||
| B | 0,001 | 0,0005 | ||||
| Ca | 0,006 | 0,006 | ||||
| CE | 0,45 | 0,43 | ||||
ISO 15590-3 L415 Flanges Mechanical and Physical Properties
The mechanical properties of grade ISO 15590-3 L415 Flange are displayed in the following table.
| Steel Grade SMTS | SMTS | Elongation | Minimum average Charpy V-notch value | Minium Charpy V-notch Value |
| N/mm2 | N/mm2 | % | J | J |
| 245 | 415 | 22 | 27 | 22 |
| 290 | 415 | 21 | 30 | 24 |
| 360 | 460 | 20 | 36 | 30 |
| 415 | 520 | 18 | 42 | 35 |
| 450 | 535 | 18 | 45 | 38 |
| 485 | 570 | 18 | 50 | 40 |
| 555 | 625 | 18 | 56 | 45 |
| The tensile requirements for intermediate grades shall be obtained by interpolation between those specified for standard grades. | ||||
ISO 15590-3 L415 Flanges Price
- USD $ 2500 Per Metric Ton - ISO 15590-3 L415 Flange
- USD $ 2500 Per Metric Ton - ISO 15590-3 L245 Flange
- USD $ 2800 Per Metric Ton - ISO 15590-3 L290 Flange
- USD $ 3050 Per Metric Ton - ISO 15590-3 L360 Flange
- USD $ 3200 Per Metric Ton - ISO 15590-3 L415 Flange
- USD $ 3610 Per Metric Ton - ISO 15590-3 L450 Flange
- USD $ 3800 Per Metric Ton - ISO 15590-3 L485 Flange
- USD $ 2600 Per Metric Ton - ISO 15590-3 L415 Carbon Steel Flange
- USD $ 3200 Per Metric Ton - ISO 15590-3 L415 Flange
- USD $ 3100 Per Metric Ton - ISO 15590-3 L415 Weldneck Flange
- USD $ 2820 Per Metric Ton - ISO 15590-3 L415 Socketweld Flange
- USD $ 2950 Per Metric Ton - ISO 15590-3 L415 Blind Flange
- USD $ 2790 Per Metric Ton - ISO 15590-3 L415 Slip On Flange
- USD $ 2100 Per Metric Ton - ISO 15590-3 L415 Lap Joint Flange
- USD $ 3320 Per Metric Ton - ISO 15590-3 L415 Threaded Flange
- USD $ 3050 Per Metric Ton - ISO 15590-3 L415 Reducing Flange
ISO 15590-3 L415 Flange Manufacturer Name and Origin
- ISO 15590-3 L415 Flange - Savoy Piping Inc., Make, Origin - India
- ISO 15590-3 L415 Flange - Ulma, Origin - Spain
- ISO 15590-3 L415 Flange - Matalfar, Origin - Italy
- ISO 15590-3 L415 Flange - Kofco, Origin - South Korea
- ISO 15590-3 L415 Flange - Melesi, Origin - Italy
- ISO 15590-3 L415 Flange - Viraj, Origin -India
- ISO 15590-3 L415 Flange - Galpetri, Origin - Italy
- ISO 15590-3 L415 Flange - Korea Flages, Origin - South Korea
- ISO 15590-3 L415 Flange - N.K Forge, Origin - Japan
- ISO 15590-3 L415 Flange - Ring Mill, Origin - Italy
- ISO 15590-3 L415 Flange - WMASS, Origin - India
- ISO 15590-3 L415 Flange - Korea Metal, Origin - South Korea
- ISO 15590-3 L415 Flange - Cladtek, Origin - South Korea
- ISO 15590-3 L415 Flange - CHW Forge Origin - India
ISO 15590-3 L415 Flange is in Ready Stock and Ready to Deliver. High Quality, Lower Cost But Best Service in Flanges
ISO 15590-3 L415 Flange Application
- Oil and Gas Industries
- Food Processing Industries
- Equipments
- Pipeline
- Power Industries
- Ship Building Industries
- Paper Industries
- Cement Industries
- Chemical Industries
ISO 15590-3 L415 Flanges Available Offer and Discounts
Buy Now ISO 15590-3 L415 Flange at an Attactive Discounted Price, Order Above USD $ 25000 are Eligible of 2% Discount. We Offer Free Insurance and Best Shipping Rates. Our Prices are Always More Competitive and without any compromise in Quality of the Material.
ISO 15590-3 L415 Flanges Types
- ISO 15590-3 L415 Welding Neck Flange Carbon Steel
- ISO 15590-3 L415 Slip On Flange Carbon Steel
- ISO 15590-3 L415 Socket Weld Flange Carbon Steel
- ISO 15590-3 L415 Lap Joint Flange Carbon Steel
- ISO 15590-3 L415 Threaded Flange Carbon Steel
- ISO 15590-3 L415 Blind Flange Carbon Steel
- ISO 15590-3 L415 Orifice Flanges Carbon Steel
- ISO 15590-3 L415 Long Welding Neck Flanges Carbon Steel
- ISO 15590-3 L415 Weldoflange Carbon Steel
- ISO 15590-3 L415 Nipoflange Carbon Steel
- ISO 15590-3 L415 Expander Flange Carbon Steel
- ISO 15590-3 L415 Reducing Flange Carbon Steel
- ISO 15590-3 L415 WNRF Flange Carbon Steel
- ISO 15590-3 L415 SORF Flange Carbon Steel
- ISO 15590-3 L415 SWRF Flange Carbon Steel
- ISO 15590-3 L415 BLRF Flange Carbon Steel
- ISO 15590-3 L415 Spectacle Blind Flange Carbon Steel
- ISO 15590-3 L415 Ring Type Joint Flange Carbon Steel
- ISO 15590-3 L415 Tongue Flange Carbon Steel
- ISO 15590-3 L415 Square Flange Carbon Steel
- ISO 15590-3 L415 Weldo Flange Carbon Steel
- ISO 15590-3 L415 Spade Flange Carbon Steel
- ISO 15590-3 L415 Ring Flange Carbon Steel
- ISO 15590-3 L415 High Hub Flanges Carbon Steel
- ISO 15590-3 L415 Forged Flange Carbon Steel
- ISO 15590-3 L415 Bleed Ring Flange Carbon Steel
- ISO 15590-3 L415 Flangeolet Flange Carbon Steel
- ISO 15590-3 L415 Raised Face Flangs Carbon Steel
- ISO 15590-3 L415 Male & Female Flange Carbon Steel
ISO 15590-3 L415 Flange Packing Shipment
ISO 15590-3 L415 Flange is Covered with Plastic Cloth and Packed in Wooden Box, Wooden Pallet and Wooden Fumigated Carrate. Our Packaging is Fully Waterproof and Safe for Transport with Proper Strips on Wooden Box, having Lifting Point.
ISO 15590-3 L415 Flange Exported Countries
We Export ISO 15590-3 L415 Flanges to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen , Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States Of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East.etc
ISO 15590-3 L415 Flange Supplying in States and Cities
We Supply ISO 15590-3 L415 Flanges Andhra Pradesh, Arunachal Pradesh, Assam, Bihar, Chhattisgarh, Goa, Gujarat, Haryana, Himachal Pradesh, Jammu and Kashmir, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Maharashtra, Manipur, Meghalaya, Mizoram, Nagaland, Odisha, Punjab, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Uttar Pradesh, Uttarakhand, West Bengal, Mumbai, Navi Mumbai, Pune, Nashik, Nagpur, Solapur, Kolhapur, Ambernath, Ahmednagar, Latur, Ahmadabad, Surat, Rajkot, Vadodara, Panaji, Madgaon, Chennai, Kolkata, Hyderabad, Bengaluru, Delhi, New Delhi, Ludhiana, Chandigarh, Raipur, Bhopal, Jamshedpur, Vishakhapatnam, Cochin, Ghaziabad, Noida, Gurugram, Bhillai, Durgapur, Vijaywada, Kanpur etc.
Savoy Piping Inc., is a well known worldwide Exporter of ISO 15590-3 L415 Flange , Savoy Piping Inc., is committed to provide each and every customer with the highest standard of customer service. We deals in ISO 15590-3 L415 Flanges in India and Overseas, offering a wide range of ISO 15590-3 L415 Flanges
