Savoy Piping Inc. we carry a full inventory of API 5L X56 PSL1 Pipe Carbon Steel Pipe products in a variety of sizes to meet the structural piping requirements for applications the water, petroleum, oil & gas and other industries. API 5L X56 PSL1 Seamless Pipe Carbon Steel Pipe can be Structural in Nature or used in Fluid, Gas, Oil Transmission.
We Supply API 5L Line Pipe in API 5L Grade B PSL1, API 5L Grade B PSL2, API 5L X42 PSL1, API 5L X42 PSL2, API 5L X46 PSL1, API 5L X46 PSL2, API 5L X52 PSL1, API 5L X52 PSL2, API 5L X56 PSL1, API 5L X56 PSL2, API 5L X60 PSL1, API 5L X60 PSL2, API 5L X65 PSL1, API 5L X65 PSL2 , API 5L X70 PSL1, API 5L X70 PSL2 .The grade indicates the testing methods required for a given application. It is critical that structural grades of Carbon Steel Pipe not be used for Pressure or Fluid applications.
Savoy Piping Inc specializes in API 5L X56 PSL1 Seamless Line Pipe with years of Experience in Manufacturing API 5L X56 PSL1 Carbon Steel Pipe we offer high quality, lower cost but the best service. As a result to that our API 5L X56 PSL1 Pipes export account today is in various countries like Iran, Iraq, Kuwait, Saudi Arabia, Oman, UAE, Singapore, Malaysia, Indonesia, South korea, Chile, Peru, Venezuela, Australia, Nigeria, Angola, Senegal, Mozambique, Algeria, Libya, Azerbaijan, Netherlands, Brazil, Norway, United Kingdom, Mexico, Canada etc.
API 5L X56 PSL1 Pipes Seamless Certified and Tested in Accordance with ISO 3183, ISO 15156, NACE MRO175 / 103, HIC, SWC, SSC, SSCC, SOUR Service, H2S, IMPACT, POST WELD HEAT TREATMENT (PWHT), IBR, High yield, IPS-M-PI-190, IPS-M-PI-221 ETC.
API 5L X56 Pipe Specification Covers Seamless and Welded Steel Line Pipe. It includes standard-weight and Extra-Strong threaded Line Pipe. It includes standard-weight and extra-strong threaded line pipe and standard-weight plain-end, regular-weight plain-end, special plain-end, extra-strong plain-end, special plain-end, extra-strong plain-end pipe; as as well as bell and spigot and through-the-flow line(TFL) pipe.The purpose of this specification is to provide standards for pipe suitable for use in conveying gas, water, and oil in both the oil and natural gas industries API 5L Line Pipe is dimensionally equivalent to A106 and A53 pipe, conforming to industry standard sizes, however it performs to different mechanical properties. One key defining characteristic of this pipe is its yield strength, where the two digit number following the pipe’s "X" grade indicates the Minimum Yield Strength (in 000's psi) of pipe produced to this grade (i.e. X52 Pipe). Grades covered by this specification are A25 ,A ,B (and the following "X" Grades) X42, X46, X52, X60, X65, & X70. The two digit number following the "X" indicates the Minimum Yield Strength (in 000's psi) of pipe produced to this grade.
X56 PSL1 API 5L grade seamless carbon steel pipe is a carbon steel steel pipe manufactured in strict accordance with API American Petroleum Institute to meet customer requirements. Savoy Piping Inc provides this API Pipes have undergone all essential non-destructive tests, including eddy current tests and water pressure tests. We offer API 5L galvanized and black finish 1 Pipes in single random lengths. H. 4 to 7 meters, twice the random length, or H. Generally, these API pipes are used to transport oil, gas, and petroleum distilleries. Savoy Piping Inc. exclusively handles Storage and manufacturing of API 5L grade Carbon Steel Pipe for oil, gas and water production in the oil and gas industry. API 5L PSL1 grade X56 pipe is available in seamless and welded styles and is commercially referred to as API 5L line pipe.
Couplings for Class A and B pipes shall be seamless and made of a grade of material that has mechanical properties at least equal to those of the pipe. Couplings for A25 and API 5L X56 PSL1 grade pipes must be made of Seamless Steel Pipe. Pursuant to the agreement between the purchaser and the manufacturer Welded couplings can be supplied to pipes of size 14 and above, provided the coupling is properly marked.
Tensile tests must be performed on each batch of steel from which the coupling is manufactured, and the coupling manufacturer must keep records of these tests. This protocol is available to purchasers for inspection. If such a test is to be performed on a completed coupling, a round sample of appropriate proportions is required. At the manufacturer's option, test specimens or strip samples as specified in ASTM E 8, "Test Methods for Voltage Testing of Metallic Materials" shall be used.
Couplings shall be free from blisters, pits, cinder marks, and other defects that would impair the efficiency of the coupling or break the continuity of the thread
API 5L X56 PSL1 Pipe Specification | API 5L / ISO 3183 Hot Rolled. |
API 5L X56 PSL1 Pipe Grades | API 5L Grade B PSL1, PSL 2 / API 5CT / API 5L X42 PSL1, PSL 2 / API 5L X46 PSL1, PSL 2 / API 5L X52 PSL1, PSL 2 / API 5L X56 PSL1, PSL 2 / API 5L X60 PSL1, PSL 2 / API 5L X65 PSL1, PSL 2 / X70 PSL1, PSL 2 / API 5L X70 PSL1 / PSL2 / API 5L X80 PSL1, PSL 2 / ISO 3183 L245 PSL1, PSL 2, ISO 3183 L290 PSL1, PSL 2, ISO 3183 L320 PSL1, PSL 2, ISO 3183 L360 PSL1, PSL 2, ISO 3183 L390 PSL1, PSL 2, ISO 3183 L415 PSL1, PSL 2, ISO 3183 L450 PSL1, PSL 2, ISO 3183 L485 PSL1, PSL 2 |
API 5L X56 PSL1 Pipe Type | Seamless |
API 5L X56 PSL1 Pipe Outer Diameter Size | 3/8" NB to 30" NB (Nominal Bore Size) |
API 5L X56 PSL1 Pipe Wall Thickness | Schedule 20 to Schedule XXS (Heavier On Request) Up to 250 mm Thickness |
API 5L X56 PSL1 Pipe Length | 5 to 7 Meters, 09 to 13 Meters, Single Random Length, Double Random Length And Customize Size. |
API 5L X56 PSL1 Pipe Ends | Plain Ends / Beveled Ends / Coupling |
API 5L X56 PSL1 Pipe Delivery Conditions | As Rolled, Normalizing Rolled, Thermomechanical Rolled / Formed, Normalizing Formed, Normalized and Tempered / Quenched and Tempered - BR / N / Q /T |
API 5L X56 PSL1 Pipe Coating | Epoxy Coating / Colour Paint Coating / 3LPE Coating. |
API 5L X56 PSL1 Pipe Other Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, PWHT etc. |
API 5L X56 PSL1 Pipe Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, API. |
API 5L X56 PSL1Pipe Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment |
API 5L X56 PSL1 Pipe Packaging | Loose / Bundle / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
API 5L X56 PSL1 Pipe Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
API 5L X56 PSL1 Pipe Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
Mass fraction, based upon heat and product analysis a | |||||||
Seamless Pipe | |||||||
C | Mn | P | S | V | Nb | Ti | |
maxb | max.b | min. | max. | max. | max. | max. | max. |
0.28 | 1.40 | - | 0.030 | 0.030 | d | d | d |
Welded Pipe | |||||||
0.26 | 1.40 | - | 0.030 | 0.030 | d | d | d |
Y.S | T.S | Elongation |
Mpa(psi) | Mpa(psi) | |
min | min | min |
390(56 600) | 490(71 100) | c |
PSL 1 | |||||||||
Grade | Chemical Composition | Mechanical Property | |||||||
C (Max) | Mn (Max) | P (Max) | S (Max) | TENSILE ( Min) | YIELD ( Min) | ||||
Psi X 1000 | Mpa | Psi X 1000 | Mpa | ||||||
A25 | CL I | 0.21 | 0.60 | 0.030 | 0.030 | 45 | 310 | 25 | 172 |
CL II | 0.21 | 0.60 | 0.030 | 0.030 | |||||
A | 0.22 | 0.90 | 0.030 | 0.030 | 48 | 335 | 30 | 210 | |
B | 0.28 | 1.20 | 0.030 | 0.030 | 60 | 415 | 35 | 245 | |
X42 | 0.28 | 1.30 | 0.030 | 0.030 | 60 | 415 | 42 | 290 | |
X46 | 0.28 | 1.40 | 0.030 | 0.030 | 63 | 435 | 46 | 320 | |
X52 | 0.28 | 1.40 | 0.030 | 0.030 | 66 | 460 | 52 | 360 | |
X56 | 0.28 | 1.40 | 0.030 | 0.030 | 71 | 490 | 56 | 390 | |
X60 | 0.28 | 1.40 | 0.030 | 0.030 | 75 | 520 | 60 | 415 | |
X65 | 0.28 | 1.45 | 0.030 | 0.030 | 77 | 535 | 65 | 450 | |
X70 | 0.28 | 1.65 | 0.030 | 0.030 | 82 | 570 | 70 | 485 |
The information here is summarized from ASTM Standards and API Specification 5L. Please see the specific standards for more information.
Grade Range | A25 Through X70 | Gr B Through X80 | Table 1 |
Size Range | 0.405 Through 80 | 4-2/1 Through 80 | Table 1 |
Type Of Pipe Ends | Plain-End, Threaded-end, Bevelled-End, Special Coupling Pipe | Plain-End | Table 1 |
Seam Welding | All Methods Continous Welding Limited to Grade A25 | All Methods Except Continous And Laser Welding | Table 1 |
Electric Welds: Welder Frequency | No Minimum | 100 Khz Minimum | 5.1.3.3.2 |
Heat Treatments of Electric Welds | Required For Grades > X42 | Required For All Grades (Gr B Through X80) | 5.1.3.3.1; J.3.3.2:6.2.7 |
Chemistry: Max C For Seamless Pipe | 0.28% For Grades > Gr B | 0.24% | tables 2a, 2b |
Chemistry: Max C For Welded Pipe | 0.26% For Grades > Gr B | 0.22% | tables 2a, 2b |
Chemistry: Max P | 0.03% | 0.03% | Tables 2a, 2b |
Chemistry: Max S | Only When Purchases Specifies Sr18 | 0.02% | Tables 2a, 2b |
Carbon Equivalent | None | Maximum Required for Each Grade | 4.2:4.3:6.1.3: Sr15.1 |
Yield Strength, Maximum | None | Maximum for Each Grade | tables 3a, 3b |
UTS, Maximum | None Required | Maximum For Each Grade | Tables 3a, 3b |
Fracture Toughness | Only When Purchaser Specifies Sr4 | Required For All Grades | 6.2.6; 9.3.5: 9.8.4; 9.10.7; |
Non-destructive Inspection of Seamless Pipes | Permitted | sr4 Mandatory | table 14 9.7.2.6 |
Repair By Welding of Pipe Body, Plate And Skelp | Permitted By Agreement | Prohibited | 5.3.2;9.7.6: B.1;b.2 |
Certification | Certificates When Specified Per Sr15 | Prohibited | 4.3;9.7.4.4;9.7.6;b.1.2;b.4 |
Traceability | Traceable Only Until All Tests are Passed Unless Sr15 Is Specified | Certificates (Sr15.1) Mandatory Traceable After Completion of Tests (Sr15.2) Mandatory |
12.1 5.6 |
Country Name | Latest Price/ Recent Updated Price 2017-18 |
API 5L X56 PSL1 Pipe Price in Indonesia | US $850 - 950 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Malaysia | US $850 - 990 / Metric Ton |
API 5L X56 PSL1 Pipe Price in United Arab Emirates | AED 3121.84 - 3489.11/ Metric Ton |
API 5L X56 PSL1 Pipe Price in Singapore | US $850 - 995 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Iran | US $850 - 950 / Metric Ton |
API 5L X56 PSL1 Pipe Price in South Korea | US $850 - 1350 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Egypt | US $850 - 1150 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Saudi Arabia | US $850 - 950 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Kuwait | US $850 - 950 / Metric Ton |
API 5L X56 PSL1 Pipe Price in South Africa | US $850 - 1100 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Qatar | US $850 - 950 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Bahrain | BD 320-358 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Oman | US $850 - 950 / Metric Ton |
API 5L X56 PSL1 Pipe Price in India | INR 56988-63692/ Metric Ton |
API 5L X56 PSL1 Pipe Price in Taiwan | US $850 - 950 / Metric Ton |
API 5L X56 PSL1 Pipe Price in Vietnam | US $850 - 1250 / Metric Ton |
API 5L X56 PSL1 Pipe Price in USA | US $850 - 1050 / Metric Ton |
API 5L Specifications Covers Seamless and Welded pipe suitable for use in conveying gas, water, oil, and other liquefied media. The attached requirements cover our offering of API 5L 45th Ed, PSL 1Seamless and Welded API 5L 45th Ed PSL 2 Seamless & Welded; and API 5L 45th Ed PSL2 Welded only.
tensile Properties for Seamless and Welded API 5L X56 PSL1 Pipe
Tensile properties data for Seamless and Welded API 5L Steel Pipe API 5L 45th Ed PSL 1, PSL 2.
Testing Requirements for Seamless and Welded API 5L X56 PSL1 Pipe
Our API 5L Grade B Seamless Pipes hydrostatic and mechanical testing information for all sizes and grades covered by the specification.
Grade A, B, A25 | X42 through X80 | |
NPS 2-1/2 and smaller --Seamless and Welded, % | +20 -- 12.5 | +15 -- 12.5 |
NPS 3 --Seamless and Welded, % | +18 -- 12.5 | +15 -- 12.5 |
NPS 4 through 18 --Seamless and Welded, % | +15 -- 12.5 | +15 -- 12.5 |
NPS 20 and larger -- Welded, % | +17.5 -- 10.0 | +19.5 -- 8.0 |
NPS 20 and larger -- Seamless, % | +15.0 -- 12.5 | +17.5 -- 10.0 |
Paint-stenciled or die-stamped manufacturer’s name or mark, Spec 5L, size, weight per foot, grade, process of manufacture, type of steel, length (NPS 4 and larger only). Test pressure when higher than tabulated (NPS 2 and larger only).
Supplemental Annexes for API 5L X52 PSL1Seamless and Welded steel Pipe
API Specification 5L contains 15 Supplemental Annexes that address special conditions and/or additional requirements.
Sabic Saudi Arabia) | Shell | ALBA (Saudi Arabia) | QAFCO(Qatar) | Maaden(Saudi Arabia) | KNPC(Kuwait) |
Kuwait Oil Company(Kuwait) | Qatar Petroleum(Qatar) | Petroleum Development Oman(Oman) | ADNOC(United Arab Emirates) | Orpic(Oman) | Takreer(Abu Dhabi) |
YASREF(Abu Dhabi) | Petrobras(Brazil) | Petronas(Malaysia) | NIOC(Iran) | NPDC(Nigeria) | Egyptian General petroleum Corporation(Egypt) |
We Export API 5L X56 PSL1 Seamless Pipe to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen, Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East.etc
Savoy Piping Inc. is a well known worldwide Exporter of API 5L X56 PSL1 Pipe is committed to provide each and every customer with the highest standard of customer service. We deals in API 5L X56 PSL1 Seamless Pipe in India and Overseas, offering a wide range of API 5L X56 PSL1 Seamless Line Pipes Content Source: Prosaic Steel & Alloys
