| Choose | When | Watch-outs |
|---|---|---|
| X70 PSL2 | ~70 ksi (485 MPa) min yield class | Confirm edition tables |
| X65 | Lower strength neighbour | Not interchangeable |
| X70 | Higher strength neighbour | Wall/design may change |
API 5L X70 PSL2 seamless OD: ____ Wall: ____ Qty: ____ Delivery condition: ____ Coating: ____ Annexes (HIC/SSC/NACE): ____ MTC: 3.1/3.2 Destination: ____
Email sales@savoypipinginc.com with destination and any IBR / NACE / TPI notes.
Savoy Piping Inc. supplies API 5L X70 PSL2 seamless line pipe for oil and gas pipeline transportation systems — commonly mapped to ISO 3183 L485.
Order by grade + PSL + product form, OD/wall, ends, delivery condition (R/N/Q/M for PSL2) and the full test / annex package.
Typical strength guide: yield min ~70 ksi (485 MPa), tensile min ~82 ksi (565 MPa). PSL2 packages typically add tighter chemistry, toughness (CVN) and more NDE/documentation than PSL1.
Related: X70 PSL2 LSAW / SAW, X70 PSL1 Seamless, X70 Seamless Hub, ISO 3183 Seamless, API 5L Seamless Hub.
API 5L covers seamless and welded steel line pipe for pipeline transportation systems. X70 is defined by minimum yield strength (~70 ksi). PSL2 sets the product specification level — chemistry, toughness and testing depth differ between PSL1 and PSL2.
Also see: API 5L seamless line pipe hub · Carbon seamless hub · CS buttweld.
State API 5L edition, grade X70, PSL2, seamless, OD/wall, ends, coating, delivery condition and MTC level (EN 10204 3.1 / 3.2). For sour service, call out NACE / HIC / SSC annexes explicitly.
This API 5L X70 Pipe Specification Covers Seamless and Welded Steel Line Pipe. It includes standard-weight and Extra-Strong threaded Line Pipe. It includes standard-weight and extra-strong threaded line pipe; and standard-weight plain-end, regular-weight plain-end, special plain-end, extra-strong plain-end, special plain-end, extra-strong plain-end pipe; as well as bell and spigot and through-the-flow line(TFL) pipe.
The purpose of this specification is to provide standards for pipe suitable for use in conveying gas, water, and oil in both the oil and natural gas industries
Grades covered by this specification are A25 ,A ,B (and the following "X" Grades), X42, X46, X52, X56, X60, X65, X70, X80. The two digit number following the "X" indicates the Minimum Yield Strength (in 000's psi) of pipe produced to this grade.
Savoy Piping Inc. Supply a full range of API 5L X70 Seamless Pipes in PSL-1 & PSL-2 line pipe.
We Exports API 5L X70 Seamless Line Pipe , Carbon API 5L X70 PSL2 Line Pipe, Carbon API 5L X70 Welded Pipe, API 5L X70 Pipe, API 5L X70 Carbon Pipe, API 5L X70 PSL2 LSAW Pipe, API 5L X70 PSL2 Welded Pipe, API 5L X70 LSAW Line Pipe, API 5L X70 PSL2 Line Pipe, Carbon Steel API 5L X70 LSAW Pipe, API 5L X70 LSAW Pipe, Carbon API 5L X70 LSAW Pipe, API 5L X70 Seamless Pipe, Carbon API 5L X70 Pipe, Carbon API 5L X70 LSAW Pipe, API 5L X70 ERW Pipe, API 5L X70 ERW Line Pipe.
Savoy Piping Inc., we carry a full inventory of API 5L X70 PSL2 Pipe Carbon Steel Pipe products in a variety of sizes to meet the structural piping requirements for Applications the water, petroleum, oil & gas and other industries. API 5L X70 PSL2 Seamless Pipe Carbon Steel Pipe can be Structural in Nature or used in Fluid, Gas, Oil Transmission.
We Supply API 5L Line Pipe in API 5L Grade B PSL1, API 5L Grade B PSL2, API 5L X42 PSL1, API 5L X42 PSL2, API 5L X46 PSL1, API 5L X46 PSL2, API 5L X52 PSL1, API 5L X52 PSL2, API 5L X56 PSL1, API 5L X56 PSL2, API 5L X60 PSL1, API 5L X60 PSL2, API 5L X65 PSL1, API 5L X65 PSL2 , API 5L X70 PSL1, API 5L X70 PSL2 .The grade indicates the testing methods required for a given Application. It is critical that structural grades of Carbon Steel Pipe not be used for Pressure or Fluid Applications.
API 5L Line Pipe can be either seamless or welded. Applications for API 5L include, but are not limited to: petroleum, petrochemical, natural gas industries, and waterworks.
API 5L Line Pipe is dimensionally equivalent to A106 and A53 pipe, conforming to industry standard sizes, however it performs to different mechanical properties. One key defining characteristic of this pipe is its yield strength, where the two digit number following the pipe’s "X" grade indicates the Minimum Yield Strength (in 000's psi) of pipe produced to this grade (i.e. X52 Pipe).
Savoy Piping Inc., is a Pipe Distributor in Middle East, Far East and Africa Region that provides API 5L line pipe from 1/2" to 64" in diameter, in grades X42, X46, X52, X60, X65, & X70.
Savoy Piping Inc. specializes in API 5L X70 PSL2 Seamless Line Pipe with years of experience in Manufacturing API 5L X70 PSL2 Carbon Steel Pipe we offer high quality, lower cost but the best service. As a result to that our API 5L X70 PSL2 Pipes export account today is in various countries like Iran, Iraq, Kuwait, Saudi Arabia, Oman, UAE, Singapore, Malaysia, Indonesia, South korea, Chile, Peru, Venezuela, Australia, Nigeria, Angola, Senegal, Mozambique, Algeria, Libya, Azerbaijan, Netherlands, Brazil, Norway, United Kingdom, Mexico, Canada etc.
API 5L X70 PSL2 Pipes Seamless Certified and Tested in Accordance with ISO 3183, ISO 15156, NACE MR0175 / 103, HIC, SWC, SSC, SSCC, SOUR Service, H2S, IMPACT, POST WELD HEAT TREATMENT (PWHT), IBR, HIGH YIELD, IPS-M-PI-19 ETC
| API 5L X70PSL2 Pipe Specification | API 5L / ISO 3183 Hot Rolled. |
| API 5L X70 PSL2 Pipe Grades | API 5L X70 PSL2 (ISO 3183 L485 when dual-mapped) |
| API 5L X70 PSL2 Pipe Type | Seamless |
| API 5L X70 PSL2 Pipe Outer Diameter Size | 3/8" NB to 30" NB (Nominal Bore Size) |
| API 5L X70 PSL2 Pipe Wall Thickness | Schedule 20 to Schedule XXS (Heavier On Request) Up to 250 mm Thickness |
| API 5L X70 PSL2 Pipe Length | 5 to 7 Meters, 09 to 13 Meters, Single Random Length, Double Random Length And Customize Size. |
| API 5L X70 PSL2 Pipe Ends | Plain Ends / Beveled Ends / Coupling |
| API 5L X65 PSL2 Pipe Delivery Conditions | As Rolled, Normalizing Rolled, Thermomechanical Rolled / Formed, Normalizing Formed, Normalized and Tempered / Quenched and Tempered - BR / N / Q /T |
| API 5L X70 PSL2 Pipe Coating | Epoxy Coating / Colour Paint Coating / 3LPE Coating. |
| API 5L X70 PSL2 Pipe Other Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, PWHT etc. |
| API 5L X70 PSL2 Pipe Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, API. |
| API 5L X70 PSL2 Pipe Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment |
| API 5L X70 PSL Pipe Packaging | Loose / Bundle / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| API 5L X70 PSL2 Pipe Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 4 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| API 5L X70 PSL Pipe Material Test Certificate | Manufacturer Test certificate As Per EN10204 3.1, 3.2 / Laboratory Test certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| mass fraction, based upon heat and product analysis % maximum | Carbon equivalent a | ||||||||||
| % maximum | |||||||||||
| Steel Grade | C (b) | Si | Mb | P | S | V | Nb | Ti | Other | CE (iiw) | CE Pcm |
| Seamless & welded Pipes | |||||||||||
| L485Q or x70Q | 0.18 | 0.4 | 1.80 | 0.025 | 0.015 | g | g | g | , l | 0.43 | 0.25 |
| Welded pipe | |||||||||||
| L485M or x70M | 0.12 | 0.4 | 1.60 | 0.025 | 0.015 | g | g | g | , l | 0.43 | 0.25 |
| Pipe Grade | Pipe Body of Seamless and Welded Pipes | Weld seam of HFW, SAW and CIW Pipes |
|||||
| Yield Strength Mpa (psi) |
Tensile Strength Mpa (psi) |
Ratio a,c rt0.5lrm | Elongation (on 50 mm or 2 in) af % |
Tensile Strength Mpa (psi) |
|||
| min | max | min | max | max | min | min | |
| L485Q or X70Q L485 or X70M |
485 (70 300) |
635 (92 100) |
570 (82 600) |
760 (110 200) |
0.93 | f | 570 (82 700) |
The information here is summarized from ASTM Standards and API Specification 5L. Please see the specific standards for more information.
| Grade Range | A25 Through X70 | Gr B Through X80 | Table 1 |
| Size Range | 0.405 Through 80 | 4-2/1 Through 80 | Table 1 |
| Type Of Pipe Ends | Plain-End, Threaded-end, Bevelled-End, Special Coupling Pipe | Plain-End | Table 1 |
| Seam Welding | All Methods Continous Welding Limited to Grade A25 | All Methods Except Continous And Laser Welding | Table 1 |
| Electric Welds: Welder Frequency | No Minimum | 100 Khz Minimum | 5.1.3.3.2 |
| Heat Treatments of Electric Welds | Required For Grades > X42 | Required For All Grades (Gr B Through X80) | 5.1.3.3.1; J.3.3.2:6.2.7 |
| Chemistry: Max C For Seamless Pipe | 0.28% For Grades > Gr B | 0.24% | tables 2a, 2b |
| Chemistry: Max C For Welded Pipe | 0.26% For Grades > Gr B | 0.22% | tables 2a, 2b |
| Chemistry: Max P | 0.03% | 0.03% | Tables 2a, 2b |
| Chemistry: Max S | Only When Purchases Specifies Sr18 | 0.02% | Tables 2a, 2b |
| Carbon Equivalent | None | Maximum Required for Each Grade | 4.2:4.3:6.1.3: Sr15.1 |
| Yield Strength, Maximum | None | Maximum for Each Grade | tables 3a, 3b |
| UTS, Maximum | None Required | Maximum For Each Grade | Tables 3a, 3b |
| Fracture Toughness | Only When Purchaser Specifies Sr4 | Required For All Grades | 6.2.6; 9.3.5: 9.8.4; 9.10.7; |
| Non-destructive Inspection of Seamless Pipes | Permitted | sr4 Mandatory | table 14 9.7.2.6 |
| Repair By Welding of Pipe Body, Plate And Skelp | Permitted By Agreement | Prohibited | 5.3.2;9.7.6: B.1;b.2 |
| Certification | certificates When Specified Per Sr15 | Prohibited | 4.3;9.7.4.4;9.7.6;b.1.2;b.4 |
| Traceability | Traceable Only Until All Tests are Passed Unless Sr15 Is Specified | certificates (Sr15.1) Mandatory Traceable After Completion of Tests (Sr15.2) Mandatory |
12.1 5.6 |
| Country Name | Latest Price/ Recent Updated Price 2017-18 |
| API 5L X70 PSL2 Pipe Price in Indonesia | US $850 - 950 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Malaysia | US $850 - 99 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in United Arab Emirates | AED 3121.84 - 3489.11/ Metric Ton |
| API 5L X70 PSL2 Pipe Price in Singapore | US $850 - 995 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Iran | US $850 - 950 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in South Korea | US $850 - 1350 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Egypt | US $850 - 1150 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Saudi Arabia | US $850 - 950 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Kuwait | US $850 - 950 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in South Africa | US $850 - 1100 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Qatar | US $850 - 950 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Bahrain | BD 320-358 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Oman | US $850 - 950 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in India | INR 56988-63692/ Metric Ton |
| API 5L X70 PSL2 Pipe Price in Taiwan | US $850 - 950 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in Vietnam | US $850 - 1250 / Metric Ton |
| API 5L X70 PSL2 Pipe Price in USA | US $850 - 1050 / Metric Ton |
API 5L Specifications Covers Seamless and Welded pipe suitable for use in conveying gas, water, oil, and other liquefied media. The attached requirements cover our offering of API 5L 4th Ed, PSL 1Seamless and Welded; API 5L 4th Ed PSL 2 Seamless & Welded; and API 5L 4th Ed PSL2 Welded only.
tensile Properties for Seamless and Welded API 5L X70 PSL2 Pipe
Tensile properties data for Seamless and Welded API 5L steel pipe API 5L 4th Ed PSL 1, PSL 2.
Testing Requirements for Seamless and Welded API 5L X70 PSL2 Pipe
Our API 5L Grade B Seamless Pipes hydrostatic and mechanical testing information for all sizes and grades covered by the specification.
| Grade A, B, A25 | X42 through X80 | |
| NPS 2-1/2 and smaller --Seamless and Welded, % | +20 -- 12.5 | +15 -- 12.5 |
| NPS 3 --Seamless and Welded, % | +18 -- 12.5 | +15 -- 12.5 |
| NPS 4 through 18 --Seamless and Welded, % | +15 -- 12.5 | +15 -- 12.5 |
| NPS 20 and larger -- Welded, % | +17.5 -- 10.0 | +19.5 -- 8.0 |
| NPS 20 and larger -- Seamless, % | +15.0 -- 12.5 | +17.5 -- 10.0 |
Paint-stenciled or die-stamped manufacturer’s name or mark, Spec 5L, size, weight per foot, grade, process of manufacture, type of steel, length (NPS 4 and larger only). Test pressure when higher than tabulated (NPS 2 and larger only).
Supplemental Annexes for API 5L X70 PSL2Seamless and Welded steel Pipe
API Specification 5L contains 15 Supplemental Annexes that address special conditions and/or additional requirements.
 Sabic Saudi Arabia) |
 Shell |
 ALBA (Saudi Arabia) |
 QAFCO(Qatar) |
 Maaden(Saudi Arabia) |
 KNPC(Kuwait) |
 Kuwait Oil Company(Kuwait) |
 Qatar Petroleum(Qatar) |
 Petroleum Development Oman(Oman) |
 ADNOC(United Arab Emirates) |
 Orpic(Oman) |
 Takreer(Abu Dhabi) |
 YASREF(Abu Dhabi) |
 Petrobras(Brazil) |
 Petronas(Malaysia) |
 NIOC(Iran) |
 NPDC(Nigeria) |
 Egyptian General petroleum Corporation(Egypt) |
API 5L X70 PSL2 seamless line pipe is used for petroleum and natural gas pipeline transportation systems — oil, gas and related transmission lines ordered to API 5L (often dual-mapped to ISO 3183 L485).
The digits after X are the minimum yield strength in ksi × 1000. X70 means about 70 ksi (485 MPa) minimum yield. Typical tensile minimum is about 82 ksi (565 MPa) — confirm against the ordered edition and PSL tables.
PSL2 adds tighter chemistry, mandatory toughness and more testing/documentation than PSL1. If the datasheet says PSL2, do not supply a PSL1 commercial substitute.
Seamless is preferred for many smaller OD / high-integrity packages. Large diameters often move to LSAW/DSAW/HSAW welded pipe — follow the approved construction on the PO.
We supply this product for domestic and export projects with MTC (EN 10204 3.1 standard; 3.2 / TPI on request). Include destination, Incoterms and inspection needs on the RFQ.
